HPF24S8 | Honeywell Remote Power Supply for Fire Alarms
- Regular price
- $1,214.10
- Sale price
- $1,214.10
- Regular price
-
$1,278.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: HPF24S8
Description
The HPF24S8 is a high-capacity, UL-listed fire alarm remote power supply with integrated battery charging designed for use with 12V or 24V fire alarm control panels. Providing up to 8 amps of regulated and filtered 24VDC power, it is ideal for powering notification appliances, system accessories, or functioning as an NAC (Notification Appliance Circuit) expander.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
Power Supplies
|
| Part Number | HPF24S8 |
| Subcategory | Power Supply |
| Product Type | Remote Power Supply with Charger |
| Output Voltage | 24 VDC, regulated and filtered |
| Output Current | 6.0A continuous, 8.0A peak (short term NAC mode) |
| Output Circuits | 4 x Class B (Style Y) or 4 x Class A (Style Z with ZNAC-4) |
| Primary Power Input | 240 VAC, 50 Hz, 1.6 A |
| Battery Type Supported | Lead-acid (up to 18 AH capacity) |
| Battery Charging Voltage | 27.6 VDC float |
| Max Battery Charge Current | 1.5 A |
| Resettable/Non-resettable | All 4 configurable (2+2 or 4 of one type) |
| Trigger Input Voltage | 9.0 to 32 VDC |
| Enclosure Dimensions | 15” H x 14.5” W x 2.75” D (38.1 x 36.8 x 7.0 cm) |
| Synchronization Support | System Sensor, Wheelock, Gentex (UL-listed) |
| Trouble Contact Output | Form-C, 5A @ 24VDC |
| Earth Fault Detection | Selectable via dip switch |
| Communication/Control | 2 x isolated input control circuits (jumpered or FACP triggered) |
| Certification Standards | UL 864 (NAC mode), UL 1481 (standalone mode) |
| Environmental Protection | Power-limiting design meets UL requirements |
| Wire Terminals | Clamp-style, supports up to 12 AWG |
| Weight | 22.00 lbs (9.98 kg) |
Information About HPF24S8
The HPF24S8 is a discontinued remote power supply from Honeywell that delivers 8 amps of filtered, regulated 24 VDC output. It supports both standalone and NAC-expander operation modes, and is fully compatible with virtually any UL 864 fire alarm control panel. The unit features a selectable battery charging circuit, synchronization support for appliances from System Sensor, Gentex, and Wheelock, and two fully-isolated trigger inputs. It is commonly used to extend NAC circuits or provide auxiliary 24V power for door holders, smoke detectors, and annunciators. The HPF24S8 also includes built-in supervision and LED diagnostics, enhancing system reliability and serviceability.
Key Features:
- High Output Capacity: Provides 6A (continuous) or up to 8A (NAC expander mode) at 24VDC.
- Battery Backup: Includes integrated charger for up to 18 AH lead-acid batteries.
- Flexible Output Configuration: Supports four Class B or four Class A NACs (with ZNAC-4).
- UL-Compliant Synchronization: Compatible with System Sensor, Wheelock, and Gentex strobes.
- Standalone or NAC Expander: Works independently or with FACP notification circuits.
- Resettable/Non-resettable Options: Configurable per output circuit with full supervision.
- Selectable AC Trouble Delay: Settable to immediate or 8-hour reporting.
- Isolated Input Control: Two fully-isolated circuits allow separate triggers or permanent enable.
- Trouble Contact Output: Form-C relay rated at 5A @ 24VDC for remote fault monitoring.
- Compact Enclosure: Lockable cabinet houses internal charger and supports 7.0 AH battery.
The HPF24S8 delivers robust power and flexibility for expanding fire alarm and auxiliary 24VDC power systems while maintaining full supervision and safety compliance.
