IC3600SLEH1 | General Electric Logic Element Card
- Regular price
- $1,209.00
- Sale price
- $1,209.00
- Regular price
-
Do you need more quantity?
Product Description P/N: IC3600SLEH1
Description
IC3600SLEH1 is an overspeed test board developed by GE. It is a part of Mark I and II control system. It combines 'OR' logic elements and 'AND' gates to generate outputs based on the inputs it receives.
Technical Specifications
Brand | General Electric |
Category | Drives |
Part Number | IC3600SLEH1 |
Subcategory | Drive Board |
Function | Logic Element Card |
Series | Mark I and II |
Information About IC3600SLEH1
The IC3600SLEH1 is what is known as a fifty-one (51) pin logic element card. This is a type of printed circuit board manufactured by General Electric for the Speedtronic Mark I and Mark II series. The Mark I and II were the first systems created for the Mark line by GE.
The IC3600SLEH1 is a large rectangular circuit board. A long grey metal piece is situated on the left border of the printed circuit board. Four (4) light-emitting diodes or LEDs are placed within this metal piece. These light-emitting diodes are red in color. A variety of capacitors in different colors and sizes are situated on the PCB. Five (5) of these capacitors are solid yellow. These yellow capacitors have a voltage of eighty (80) volts. There are also three (3) small capacitors aligned on the left end of the IC3600SLEH1. These capacitors are mostly silver with red or orange on either end. Many small transistors can be found near the center of the IC3600SLEH1. These transistors are mostly black with yellow on top. Each transistor is shaped like a half-circle. Long series of small resistors are featured on either side of the IC3600SLEH1 as well as in the center. On the right side of the IC3600SLEH1, there are a total of forty-two small resistors. These resistors are mostly red. They are arranged into groups of either nine (9) or eight (8). Two groups of nine (9) are situated at the top of the IC3600SLEH1 and the three (3) groups on the bottom half contain eight (8) resistors each.
Manufacturer information
General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
IQElectro 2 Year Warranty
IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.Warranty Terms and Conditions
