IC3600SSZB1 | General Electric Speed Control Board

Description

The IC3600SSZB1, designated as a speed control board, is a type of printed circuit board (PCB) within the Mark I-II series by General Electric. The Mark I-II series, first introduced in 1969 and 1973 respectively, represents the earliest iterations of the Speedtronic Mark line, renowned for their turbine management capabilities spanning nearly five decades.

Physically, the IC3600SSZB1 features a long metal plate on its left side, housing a large red LED (light-emitting diode) at its center, connected to the circuit board with white wires. Adjacent to this plate are four potentiometers, with two blue and two black variants. The blue potentiometers are paired at the edge, while the larger black potentiometer resides at the bottom half, with the smaller black variant positioned between the blue ones. Each potentiometer features a knob for resistance adjustment.

Technical Specifications

Information About IC3600SSZB1

The IC3600SSZB1, produced by General Electric, functions as a speed control board within the Mark I-II series. The Mark I-II series represents the earliest iterations of the Speedtronic Mark line, renowned for their turbine management capabilities spanning nearly five decades, with initial introductions in 1969 and 1973 respectively.

Physically, the IC3600SSZB1 is a printed circuit board featuring a long metal plate on its left side, housing a large red LED (light-emitting diode) at its center, connected to the circuit board with white wires. Adjacent to this plate are four potentiometers, with two blue and two black variants. The blue potentiometers are paired at the edge, while the larger black potentiometer resides at the bottom half, with the smaller black variant positioned between the blue ones. Each potentiometer is equipped with a small knob for resistance adjustment.

Furthermore, the IC3600SSZB1 is populated with numerous resistors, primarily light blue in color, distinguished by colorful bands symbolizing their resistance values. Additionally, the board features a variety of transistors in various shapes and sizes, contributing to its functionality as a speed control component.

Manufacturer information

General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
