IC3600SVSE1 | General Electric Speedtronic Speed Sensor Circuit Board
- Regular price
- $2,782.00
- Sale price
- $2,782.00
- Regular price
-
Do you need more quantity?
Product Description P/N: IC3600SVSE1
Description
The IC3600SVSE1, developed by General Electric, is designed to function as part of the Mark I-II turbine management series within the Speedtronic Mark series. The Mark I and Mark II are early iterations of this series. This printed circuit board (PCB) is specifically designated as a speed sensor circuit board.
Featuring seven blue potentiometers along its left side, six of uniform size and one smaller, the IC3600SVSE1 allows for variable resistance adjustment through silver knobs associated with each potentiometer. Additionally, a silver capacitor is present among the potentiometers.
The board integrates seven integrated circuits (ICs), each hosting an array of small components such as diodes, resistors, and capacitors. Two rectangular capacitors, one orange and one red, are positioned near the blue potentiometers. Furthermore, three round silver transistors, one large and two small, and four black half-circle-shaped transistors are distributed across the board.
Technical Specifications
Brand |
General Electric |
Model |
MARK II |
MPN |
IC3600SVSE1 |
Country/Region of Manufacture |
United States |
Controller Platform |
MARK II |
Information About IC3600SVSE1
The IC3600SVSE1, developed by General Electric, serves as an integral component of the Mark I-II turbine management series within the Speedtronic Mark series. Representing a printed circuit board (PCB), it functions specifically as a speed sensor circuit board.
Comprising seven blue potentiometers positioned along the left side of the PCB, six of uniform size and one smaller, the IC3600SVSE1 allows for variable resistance adjustment facilitated by silver knobs associated with each potentiometer. Additionally, one silver capacitor is situated among the potentiometers.
The board integrates seven integrated circuits (ICs), each hosting an array of small components including diodes, resistors, and capacitors. Two rectangular capacitors, one orange and one red, are positioned in proximity to the blue potentiometers. Furthermore, three round silver transistors, one large and two small, and four black half-circle-shaped transistors are distributed across the board.
A variety of diodes and resistors populate the IC3600SVSE1, arranged in rows. Among these, several resistors exhibit light blue coloration with bands in combinations of black, red, orange, green, yellow, and other hues, while the remaining resistors are dark red, also featuring bands in various colors.
Manufacturer information
General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
