IC670ALG320 | Ge Fanuc 4-Point Analog Current / Voltage Source Output Module
- Regular price
- $1,197.00
- Sale price
- $1,197.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: IC670ALG320
Description
The IC670ALG320 is a 4-Point Analog Current/Voltage Source Output Module from the GE Fanuc Field Control series. It features four single-ended output channels that are configurable for 0-20 mA, 4-20 mA, and 0-10 VDC output signals. This module offers a 12-bit resolution with 1 LSB linearity across all ranges and outputs. It requires an external power supply ranging from 20-29 VDC, with 24 VDC being typical.
Technical Specifications
| Brand | GE FANUC |
| Category | PLCs/Machine Control |
| Part Number | IC670ALG320 |
| Subcategory | PLC Module/Rack |
| Series | Field Control |
| Wiring configuration | Single-ended |
| Output signal, nominal | 0-20 mA / 4-20 mA; 0-10 VDC |
| Description | Analog output module |
| Product Description | 4-Point Analog Current / Voltage Source Output Module |
| No of Channels | Four (4) Current / Voltage Source outputs |
| Analog resolution | 4.0 µA @ 4-20 mA; 50 µA @ 0-20 mA; 0-10 VDC @ 2.5 mV |
| Current | 4-20 mA |
| Output signals | 0-20 mA; 4-20 mA; 0-10 VDC; 0-12.5 VDC |
| ADC Conversion resolution | 12 bits |
| Voltage | 0-10 Volts |
| Isolation | 1500 VAC for 1 minute, 250 VAC continuous |
| External Power supply | 20-29 VDC, 5 % maximum ripple |
| Output Data | 4 words |
| Conversion time @ 1MHz clock | 60 Microseconds per channel, typical |
| Isolation to Ground and Logic | 1500 Volts AC |
| Nominal Supply voltage | 24 VDC |
| Analog resolution | 4.0 µA @ 4-20 mA; 5.0 µA @ 0-20 mA; 2.5 mV @ -10 VDC; 0-12.5 VDC @ 3.125 mV |
| Current input | Stand-by: 80 mA, typical: Operating: 180 mA, maximum |
| Digital Resolution | 12 bits, typical |
| Current Drawn from BIU power supply | 51 mA, maximum |
| Linearity | 1 LSB resolution value |
| Temperature coefficient | +/-.002% of value per degree C, typical, +/-.005% of value per degree C, maximum |
| Input Types | Isolated and Differential |
| Module Power Dissipation | 1.4 Watts, minimum; 4.3 Watts, maximum |
| Input Current | Standby: 80 mA Operating: 180 mA (including loop current) |
| Ground to Logic Isolation | 1500 VAC for 1 minute; 250 VAC, continuous |
| Output grouping | Single group |
| Output wiring | Single-ended |
Information About IC670ALG320
The IC670ALG320 is an analog output module from GE Fanuc’s Field Control I/O series, commonly used to control devices such as modulating control valves, dampers, louvers, positioners, and for signal retransmission to panel meters, signal isolators, signal splitters, controllers, and data loggers.
This module functions as a current and voltage sourcing output module and includes an EMI filter and an Analog to Digital Converter (ADC) for each channel. The ADC provides a 12-bit conversion resolution and a linearity of 1 LSB on all ranges. For a 0-20 mA range, the resolution is 5.0 microamperes, while for a 4-20 mA range, it is 4.0 microamperes. For a 0-10 VDC range, the resolution is 2.5 mV.
The module includes one group of outputs with isolation rated at 1500 VAC for 1 minute and 250 VAC continuously. It requires an external power supply of 20-29 VDC with a maximum ripple of 5%. The stand-by current is 80 mA, the operating current is 180 mA, and the power dissipation ranges from 1.5 to 4.3 Watts. It draws a maximum of 51 mA from the Bus Interface Unit (BU) power supply.
For optimal noise immunity, it is recommended to use instrumentation-grade shielded twisted or 3-pair twisted wire, with the shield wire connected to the grounding bar nearest the module.
The IC670ALG320 provides 4 current/voltage outputs, supporting 4-20 mA and 0-10 V ranges, which can be adjusted using a jumper on the I/O terminal block. The module can be scaled to meet different application requirements through configuration settings. It also features an LED to indicate field and backplane power status.
Manufacturer information
GE FANUC, now part of Emerson Automation Solutions, was a leading provider of industrial automation and control systems. Known for innovative solutions, GE FANUC played a key role in advancing manufacturing, offering a range of products including PLCs, CNCs, and HMI solutions.
