IC697CPX928 | GE Fanuc | CPU
- Regular price
- $16,586.00
- Sale price
- $16,586.00
- Regular price
-
Do you need more quantity?
Product Description P/N: IC697CPX928
Description
The IC697CPX928, manufactured by GE Fanuc under the Series 90-70, is a Central Processing Unit (CPU) module designed for industrial applications. This CPU module is equipped with 6MB of battery-backed memory and features 256KB of non-volatile user flash memory. Operating at a processor speed of 96MHz, it achieves a typical scan rate of 0.4 µs per Boolean function.
The IC697CPX928 CPU module provides communication interfaces, including one (1) RS232 serial port, two (2) RS485 serial ports, and one (1) Factory Reset port. These interfaces enable connectivity and data exchange within the industrial automation system.
Technical Specifications
Specifications
Manufacturer |
GE Fanuc |
Series |
Series 90-70 |
Part Number |
IC697CPX928 |
Product Type |
CPU |
Compatible With |
GE Fanuc Series 90-70 PLCs |
Microprocessor |
80486DX4 |
Clock Speed |
96 MHz |
RAM |
6 MB |
Current |
3.1 Amps |
Serial Ports |
3 |
Battery: Shelf life |
5 years at 20o C (68o F); 6 months nominal without applied power |
Current required from 5V bus |
3.1 Amps nominal |
Operating Temperature |
0 to 60oC (32oF to 140oF); 70 CFM forced air required, 0 to 50oC (32oF to 122oF) without forced air |
Time of Day Clock accuracy |
3.5 seconds per day maximum |
Elapsed Time Clock accuracy |
0.01% maximum |
Serial Ports |
Port 1: RS-232 compatible, Port 2: RS-485 compatible (optocoupler isolated), Port 3: RS-485 compatible (not isolated) |
Programmer Serial Attachment |
or other serial devices |
Protocols supported |
SNP Slave only |
VME Compatibility |
System designed to support the VME standard C.1 |
Information About IC697CPX928
The GE Fanuc IC697CPX928 is a Central Processing Unit (CPU) module belonging to the Series 90-70 lineup. This CPU features 6MB of battery-backed memory along with 256KB of non-volatile user flash memory. Operating at a processor speed of 96MHz, it boasts a typical scan rate of 0.4 µs per Boolean function.
In terms of connectivity, the IC697CPX928 offers One (1) RS232 serial port, Two (2) RS485 serial ports, and One (1) Factory Reset port. These ports facilitate communication and configuration tasks within the control system environment.
With its robust memory capacity and processing capabilities, the IC697CPX928 serves as a reliable component for industrial automation and control applications. It provides the necessary computational power and memory resources to handle complex control tasks and data processing requirements.
Designed to meet the demands of industrial environments, the IC697CPX928 is built for durability and reliability. Its rugged construction ensures reliable performance even in harsh operating conditions.
The IC697CPX928 is compatible with various peripherals and devices commonly used in industrial automation systems. Its versatile communication ports enable seamless integration with other components of the control system architecture.
Furthermore, the IC697CPX928 supports advanced features and functions essential for effective control and monitoring of industrial processes. Its flexible configuration options and user-friendly interface make it easy to set up and manage within a control system environment.
Backed by the reputable GE Fanuc brand, the IC697CPX928 adheres to high-quality standards and undergoes rigorous testing to ensure optimal performance and reliability. It meets the stringent requirements of industrial applications, making it a preferred choice for system integrators and automation engineers.
Manufacturer information
GE FANUC, now part of Emerson Automation Solutions, was a leading provider of industrial automation and control systems. Known for innovative solutions, GE FANUC played a key role in advancing manufacturing, offering a range of products including PLCs, CNCs, and HMI solutions.
