IDEC FL1F-H12RCE SmartRelay 12 I/O CPU with LCD Display
- Regular price
- $662.00
- Sale price
- $662.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FL1F-H12RCE
Description
IDEC FL1F-H12RCE is a SmartRelay CPU module with 12 embedded I/O points, an LCD display, and relay outputs. It operates from 12–24 VDC and includes Ethernet, Modbus TCP, a Micro SD memory slot, and built-in web-server functionality for industrial control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | IDEC |
| Category | Industrial Automation |
| Part Number | FL1F-H12RCE |
| Subcategory | Smart Relays |
| Series | FL1F SmartRelay |
| Product Type | SmartRelay CPU Module |
| Analog Inputs | 4 Inputs, 0–10 VDC capable |
| Outputs | 4 Relay Outputs |
| Output Rating | 10 A Relay Outputs |
| Supply Voltage | 12–24 VDC |
| Ethernet Port | 1 |
| Programming | Function Block / Ladder |
| High-Speed Counter | 5 kHz |
| Memory Interface | Micro SD |
| Display | LCD with LED Backlight |
| Expansion Modules | Up to 12 |
| Operating Temperature | -20°C to +55°C |
| Hazardous Location Rating | Class I Division 2 |
| Weight | 0.53 lb |
Information About FL1F-H12RCE
The FL1F-H12RCE belongs to IDEC’s FL1F SmartRelay Series and combines a programmable controller with an integrated operator display. The module provides eight inputs, including four inputs configurable for 0–10 VDC analog signals, and four relay outputs. It supports Function Block and Ladder programming, with up to 12 expansion modules available for increasing the system I/O capacity. Ethernet communication, Modbus TCP, real-time clock functionality, and mobile-app access provide additional control and monitoring capabilities.
Key Features:
- 12 Embedded I/O: Provides 8 inputs and 4 relay outputs in the CPU module.
- LCD Display: Includes an integrated LCD operator interface for local monitoring and configuration.
- DC Supply: Operates from a 12–24 VDC supply.
- Ethernet Interface: Provides an embedded Ethernet port for network communication.
- Modbus TCP: Supports Modbus TCP communication for industrial automation networks.
- Web Server: Provides browser-based remote monitoring and control functionality.
- Expansion Capability: Supports up to 12 expansion modules for additional I/O.
- Programming: Supports Function Block and Ladder programming methods.
The FL1F-H12RCE delivers the reliability and precision required for compact PLC control, machine automation, and industrial monitoring applications.
