IFP-2100 | Farenhyt Intelligent Fire Alarm Control Panel 2100 Points Red
- Regular price
- $1,842.00
- Sale price
- $1,842.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: IFP-2100
Description
The Farenhyt IFP-2100 is a high-capacity intelligent addressable fire alarm control panel with one built-in SLC and dual-path IP/POTS communication. It supports up to 2100 addressable devices with expanders and includes eight configurable Flexput circuits for NAC or auxiliary power distribution.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Farenhyt |
| Category | Fire Alarm Systems |
| Part Number | IFP-2100 |
| Subcategory | Addressable Fire Alarm Control Panel |
| Type | Intelligent addressable FACP |
| Device Capacity | Up to 2100 (IDP/SK) or 2032 (SD) addressable points |
| Built-In SLC | 1 loop, supporting 159 detectors + 159 modules (IDP/SK) or 127 SD devices |
| Expandability | Additional SLC loops via expander modules |
| Flexput Circuits | 8 configurable circuits, up to 3 A each, 9 A total |
| Relays | 1 Form C trouble relay, 2 programmable Form C relays |
| Communication | Built-in IP and POTS reporting; optional cellular communicator |
| Networking | Supports up to 32 networked panels via copper or fiber |
| Programming | Onboard keypad or PC via USB with HFSS; JumpStart auto programming |
| Software Zones | 999 zones and 999 output groups |
| Features | Drift compensation, maintenance alerts, alarm verification |
| Annunciators | Supports up to 63 SBUS devices (LCD, LED annunciators, and modules) |
| Primary Power | 120 VAC 60 Hz, 5 A or 240 VAC 50/60 Hz, 2.8 A |
| Battery Support | Up to two 18 Ah batteries; charger supports 17–55 Ah |
| Cabinet Type | Red, surface-mount enclosure |
| Weight | 45 lbs |
Information About IFP-2100
The IFP-2100 is Farenhyt’s advanced addressable fire alarm control panel engineered for large-scale fire detection and life safety applications. It begins with a single built-in signaling line circuit and scales up to 2100 addressable devices using SLC expanders, offering flexibility for a wide range of system sizes. With eight on-board Flexput circuits configurable as NAC outputs or auxiliary power, it provides adaptable wiring and efficient power distribution. The system integrates dual-path IP/POTS communication by default and can be upgraded with optional cellular reporting, ensuring reliable connectivity to monitoring centers. Additional features include JumpStart auto programming, 999 software zones, drift compensation with maintenance alerts, and full support for up to 32 networked panels.
Key Features:
- Large System Capacity: Scales up to 2100 addressable devices (IDP/SK) or 2032 (SD), suitable for high-occupancy facilities and complex installations.
- Built-In SLC Loop: Provides immediate support for up to 159 detectors and 159 modules with IDP/SK or 127 SD devices, expandable with additional loops.
- Eight Flexput Circuits: Each output configurable as either a NAC or auxiliary power source, rated up to 3 A per circuit and 9 A system total, enabling design flexibility.
- Dual-Path Communications: Integrated IP and POTS connectivity for redundant reporting to central monitoring, with optional cellular backup for maximum reliability.
- Robust Networking: Capable of connecting up to 32 panels over copper or fiber, allowing system-wide integration across large campuses or multi-building sites.
- Software Intelligence: Offers JumpStart auto programming, 999 programmable zones, and 999 output groups, simplifying system configuration and expansion.
- Advanced Detector Management: Features drift compensation, maintenance alerts, and alarm verification for improved accuracy and reduced false alarms.
- Programmable Relays: Includes one dedicated Form C trouble relay and two programmable Form C relays for custom system integration with auxiliary devices.
- Annunciator Compatibility: Supports up to 63 SBUS annunciators, providing flexible remote display and control options.
- Strong Power & Battery Support: Operates on 120/240 VAC with charging capacity for 17–55 Ah batteries, ensuring extended standby operation in emergencies.
- User-Friendly Programming: Can be configured from the front keypad or PC via USB with HFSS software for convenience and efficiency.
- Compliance Ready: Fully designed to meet fire protection and life safety requirements with reliable monitoring and reporting features.
The IFP-2100 delivers the reliability and precision required for high-capacity, network-ready fire detection and emergency communication in large facilities.
