IFP-75B | Farenhyt Intelligent Addressable Fire Alarm Control Panel 150 Points Black
- Regular price
- $1,359.00
- Sale price
- $1,359.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: IFP-75B
Description
The Farenhyt IFP-75B is an intelligent addressable fire alarm control panel in a black cabinet, supporting up to 150 IDP/SK points or 75 Hochiki SD devices. It includes two configurable Flexput circuits, a built-in dual-path IP/POTS communicator, and JumpStart auto-programming for simplified setup.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Farenhyt |
| Category | Fire Alarm Systems |
| Part Number | IFP-75B |
| Subcategory | Addressable Fire Alarm Control Panel |
| Type | Intelligent addressable FACP |
| Device Capacity | 150 IDP/SK (75 detectors + 75 modules) or 75 SD devices |
| SLC Loops | 1 |
| NAC/Flexput Circuits | 2 Class B or 1 Class A, 1.0 A per circuit, 2.5 A total |
| Power Input | 120 VAC, 60 Hz, 1.5 A max |
| Output Voltage | 27.4 VDC |
| Accessory Power | 2.5 A total, power-limited |
| Battery Support | Two 7 Ah internal; charger supports 7–35 Ah |
| Communicator | Built-in dual-path IP/POTS |
| Networking | Up to 32 panels via optional SK-NIC card |
| Software Zones | 125 |
| Output Groups | 125 |
| Event History | 1,000 events |
| Programming | JumpStart auto-programming and keypad configuration |
| Cabinet Color | Black |
| Dimensions | Standard Farenhyt cabinet sizing |
| Weight | 15 lbs |
Information About IFP-75B
The IFP-75B is part of the Farenhyt intelligent addressable fire alarm control panel family, built for small to mid-sized applications that require robust features in a compact package. It supports one SLC loop with a maximum capacity of 150 IDP/SK points or 75 SD devices, making it well-suited for offices, retail, and institutional facilities. The panel includes two Flexput circuits that can function as NACs or auxiliary power outputs, delivering up to 2.5 amps total. With its built-in IP/POTS communicator, JumpStart auto-programming, and support for networking up to 32 panels, the IFP-75B offers flexibility, reliability, and compliance with modern fire safety standards.
Key Features:
- Intelligent Addressable System: Supports up to 150 addressable devices (IDP/SK) or 75 SD devices on a single SLC loop.
- Configurable Flexput Circuits: Provides two Class B or one Class A NACs, or auxiliary power, with 2.5 A total capacity.
- Built-In Communications: Integrated dual-path IP and POTS communicator for reliable central station reporting.
- JumpStart Auto Programming: Simplifies system setup, reducing installation and configuration time.
- Event Storage: Maintains a 1,000-event history log for diagnostics, compliance, and service records.
- Software Control: Offers 125 programmable zones and 125 output groups for flexible system design.
- Networking Capability: Supports up to 32 networked panels with the SK-NIC card option.
- Compact, Black Cabinet: Provides a modern appearance while housing system components securely.
- Power & Battery Support: Operates on 120 VAC with charging capacity for up to 35 Ah batteries.
- Standards Compliance: Meets NFPA requirements for supervision, communication, and notification.
The IFP-75B delivers the reliability and precision required for small to mid-sized intelligent fire alarm applications with flexible programming and communication features.
