IS200EDEXG1B | General Electric De-Excitation Control Board

Description

The IS200EDEXG1B from General Electric is a De-Excitation Control Board used in turbine generator systems. It is responsible for rapidly reducing excitation in the generator during shutdown or fault conditions, ensuring a safe and controlled process. This board enhances system protection by preventing over-voltage and other potential issues, playing a critical role in maintaining the stability and reliability of the generator's operation during critical events.

Technical Specifications

Information About IS200EDEXG1B

The IS200EDEXG1B is a De-Excitation Control Board designed by General Electric as part of the Innovation Series, specifically under the EX2100 family of products. This board plays a pivotal role in the precise management of de-excitation processes within various industrial drive systems. By controlling the de-excitation mechanism, the IS200EDEXG1B ensures that generator field currents are safely and efficiently reduced to zero when required, thus safeguarding the system from potential electrical faults and improving overall operational stability.

This board is categorized as a Drive Board and serves a dual function as a De-Excitation Bridge and Protection Board, making it integral to the proper functioning of generator control systems. Its primary function is to manage the controlled dissipation of energy stored in the generator field, which is crucial during shutdown or emergency conditions to prevent damage to the machine and associated equipment. The de-excitation process must be handled with precision to avoid abrupt changes that could cause mechanical stress or electrical surges, and the IS200EDEXG1B is designed to fulfill this critical requirement.

The IS200EDEXG1B is equipped with six configurable jumpers, identified as JP1 through JP6, allowing for customizable operational settings based on specific application needs. These jumpers provide flexibility in configuration, enabling the board to be adapted for different system requirements and ensuring compatibility with a wide range of setups within the EX2100 series.

In terms of connectivity, the IS200EDEXG1B features two D-Pin connectors. These connectors are vital for establishing reliable electrical connections between the board and other components in the drive system, facilitating seamless communication and control. The robust design of these connectors ensures that the board maintains a consistent and secure interface, which is essential for maintaining the integrity of the de-excitation process.

The Innovation Series, to which the IS200EDEXG1B belongs, is renowned for its advanced technological capabilities and reliability in demanding industrial environments. The EX2100 series, specifically, is recognized for its state-of-the-art excitation control solutions that provide superior performance in power generation applications. The IS200EDEXG1B is a testament to this legacy, offering high efficiency, durability, and precise control that are essential for the reliable operation of large-scale generators.

Moreover, the IS200EDEXG1B's design includes several protection features to guard against electrical faults, thereby enhancing the safety and longevity of the equipment. Its ability to handle the dynamic conditions of de-excitation with high precision ensures that the generator and associated systems remain protected from potential damage due to overvoltage or excessive current conditions.

In summary, the IS200EDEXG1B De-Excitation Control Board is a crucial component within GE's Innovation Series, specifically tailored for the EX2100 line of products. It provides essential control over the de-excitation process, ensuring that generator fields are safely and efficiently de-energized. With configurable jumpers for flexible operation and robust D-Pin connectors for secure communication, this board is designed to meet the rigorous demands of modern industrial applications, providing both reliability and protection in critical operational environments.
