IS200STAIH2ACB | General Electric Compact Analog Input Terminal Board
- Regular price
- $8,710.00
- Sale price
- $8,710.00
- Regular price
-
Do you need more quantity?
Product Description P/N: IS200STAIH2ACB
Description
The IS200STAIH2ACB, developed by General Electric (GE), serves as a component within the Mark VI series, which is part of GE's Mark lineup. The Mark systems are designed to oversee and automate various functions of industrial gas and steam turbines. Functioning as a DINrail board, the IS200STAIH2ACB is a compact printed circuit card (PCB) equipped with multiple electronic components.
At the bottom edge of the IS200STAIH2ACB, a single large solid green terminal block is positioned, potentially accommodating up to twenty-four small silver cube-shaped terminals. Adjacent to this terminal block, a series of diodes, identified with the initial "D," are arranged linearly. Additionally, the board features fourteen black potentiometers or variable resistors, with ten arranged horizontally across the center and four grouped vertically at the top right corner.
Technical Specifications
Part No. |
IS200STAIH2ACB |
Manufacturer |
General Electric |
Country of Manufacture |
United States of America (USA) |
Size |
15.9 cm high x 10.2 cm wide |
Temperature |
-30 to +65°C |
Technology |
Surface mount |
Product Type |
Compact Analog Input Terminal Board |
Availability |
In Stock |
Series |
Mark VIe |
Information About IS200STAIH2ACB
The IS200STAIH2ACB is a component designed by General Electric (GE) for integration into the Mark VI series, which is part of GE's Mark lineup. Mark systems are utilized to manage and automate various functions within industrial gas and steam turbines. This specific device, the IS200STAIH2ACB, serves as a DINrail board.
Physically, the IS200STAIH2ACB is a small printed circuit board (PCB) packed with diverse electronic components. Positioned along the bottom edge is a single large terminal block, distinguished by its solid green color. This terminal block accommodates a minimum of twenty-four (24) small metal terminals, each silver-colored and cube-shaped. Directly above this terminal block, a row of diodes is arranged, featuring rectangular black units, each labeled with the initial "D."
The IS200STAIH2ACB further incorporates fourteen (14) black potentiometers or variable resistors. Ten (10) of these potentiometers are arranged horizontally across the center of the board, while the remaining four (4) are grouped vertically at the top right corner. Adjacent to these four potentiometers is a component identified as a jumper port, characterized by its black and white appearance and metal pins.
Manufacturer information
General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
