Product Description P/N: IS200TTURH1B

Description / Specifications

Description

The IS200TTURH1B by General Electric serves as a Turbine Terminal Board designed for use within the Mark VIe control system. As part of GE's advanced Speedtronic series, the Mark VIe represents the pinnacle in managing gas or steam turbine systems.

This terminal board features multiple connectors, including two terminal strips with two rows of screw-type connections each, facilitating straightforward installation and maintenance. It also includes male and female d-shell connectors for additional connectivity options. The board incorporates essential components such as transformers, relays, capacitors, diodes, resistors, and variable resistors, all marked with reference designations for easy identification and troubleshooting. Codes and other informational markings aid in proper wiring and placement during installation.





Technical Specifications



Part No

IS200TTURH1B

Manufacturer

General Electric

Function

Turbine Protection Input Terminal Board

Series

Mark VI

Number of Inputs

12

Operating Temperature

-30 to 65°C

Power Supply Voltage

125 V dc

Technology

Surface Mount

Board Size

33.0 cm high x 17.8 cm

Shaft Voltage

5 V dc

MPU Pulse Rate Range

2 Hz to 20 kHz







Information About IS200TTURH1B

The General Electric IS200TTURH1B is a specialized Turbine Protection Input Terminal Board designed for use within the Mark VI series, a leading solution in industrial control and automation systems. This terminal board plays a critical role in monitoring and protecting turbine systems, ensuring safe and efficient operation under a wide range of conditions. Manufactured by General Electric, the IS200TTURH1B is engineered with precision and durability in mind, making it a reliable component in turbine protection applications.

This terminal board is equipped with 12 input channels, providing ample capacity to monitor multiple critical parameters within a turbine system. The 12 inputs are designed to handle various sensor signals, allowing the board to effectively gather data necessary for turbine protection and control. This capability is essential in ensuring that the turbine operates within safe limits, preventing potential damage or operational failures.

The IS200TTURH1B operates within a temperature range of -30 to 65°C, making it suitable for deployment in diverse environmental conditions. This wide operating temperature range ensures that the board can function reliably in both extreme cold and heat, which is often encountered in industrial settings. The board's resilience to temperature fluctuations contributes to its long-term reliability and stability, reducing the likelihood of operational interruptions due to environmental factors.

The power supply voltage for the IS200TTURH1B is 125 V dc, a standard voltage level that ensures consistent and stable power delivery to the board. This voltage supports the board's functionality, enabling it to perform its monitoring and protection tasks without interruption. The stable power supply is crucial for maintaining the integrity of the data collected by the board, which is used to make real-time decisions regarding turbine operation.

In terms of technology, the IS200TTURH1B utilizes surface mount technology (SMT), which enhances the board's performance and durability. SMT allows for more components to be placed on the board in a compact and efficient layout, improving the board's overall functionality while reducing its size. This technology also contributes to better thermal management and electrical performance, ensuring that the board can handle the demands of continuous operation in a high-stress industrial environment.

The board measures 33.0 cm in height and 17.8 cm in width, making it a compact yet powerful component that can be easily integrated into existing turbine protection systems. The compact size of the IS200TTURH1B allows it to fit within standard control cabinets and enclosures, optimizing space usage and simplifying installation procedures.

A notable feature of the IS200TTURH1B is its shaft voltage monitoring capability, with a voltage rating of 5 V dc. This feature is essential for detecting and managing electrical discharges that could potentially damage the turbine's shaft or other critical components. By monitoring shaft voltage, the board helps prevent electrical arcing and other issues that could lead to costly repairs or downtime.

The MPU (Magnetic Pickup Unit) pulse rate range of the IS200TTURH1B is between 2 Hz and 20 kHz, offering a wide range of detection capabilities. This range allows the board to accurately monitor the rotational speed of the turbine, which is crucial for ensuring that the turbine operates within its designed speed limits. Accurate speed monitoring is vital for both performance optimization and protection, as it helps prevent overspeed conditions that could lead to mechanical failure.

In summary, the General Electric IS200TTURH1B Turbine Protection Input Terminal Board is a highly reliable and efficient solution for monitoring and protecting turbine systems. With its 12 input channels, wide operating temperature range, and advanced surface mount technology, this board is designed to deliver consistent performance in demanding industrial environments. Its compact size, shaft voltage monitoring, and extensive MPU pulse rate range make it an indispensable component in the Mark VI series, ensuring the safe and efficient operation of turbines in various applications.
