IS220PVIBH1A | General Electric Vibration Control Module Mark VI
- Regular price
- $12,399.00
- Sale price
- $12,399.00
- Regular price
-
Do you need more quantity?
Product Description P/N: IS220PVIBH1A
Description
The IS220PVIBH1A is a Vibration Control Module used in the Mark VI control system. It is designed for vibration monitoring and control in industrial applications. This module provides input processing for vibration sensors and delivers data to the control system for analysis and corrective action. It is used primarily for monitoring rotating machinery.
Technical Specifications
Part # |
IS220PVIBH1A |
Category |
Sensors & Switches |
Subcategory |
Vibration Transmitter |
Ambient Temperature Range |
-30 to 65 °C |
Board Compatibility |
Vibration Terminal Board (TVBA) |
Channels |
Thirteen for Proximity and Vibration |
Common Mode Voltage |
Min. 5 VDC |
Dimensions |
3.25" high x 1.65" wide x 4.78" deep |
Frame Rates |
3.125, 6.25, 12.5, 25, 50, and 100 Hz |
Functional Acronym/Abbreviation |
PVIB |
LED Indicators |
4 |
Probe Power |
-24 VDC, 12 mA load per transducer |
Status LEDs |
Attn, Pwr, Link, TxRx |
Revisions |
Rev. A, Rev. B, Rev. C, Rev. D |
Information About IS220PVIBH1A
The IS220PVIBH1A Vibration Control Module is an advanced component designed for use in vibration monitoring and control within industrial systems, specifically within the Mark VI control platform. This module is categorized under Sensors & Switches and serves as a vibration transmitter capable of processing data from vibration and proximity sensors. The module plays a critical role in monitoring and protecting rotating machinery by providing real-time data that can be used for diagnostics and corrective action to ensure the optimal performance and longevity of equipment.
Designed to operate in a wide range of industrial environments, the IS220PVIBH1A module is built to withstand ambient temperatures ranging from -30 to 65°C. This temperature range ensures reliable performance in both standard and more extreme conditions commonly encountered in heavy-duty industrial applications. Its robust design also accommodates the demands of high-stress environments where precision vibration monitoring is essential for maintaining operational efficiency.
The module is compatible with the Vibration Terminal Board (TVBA), which serves as the connection interface for various proximity and vibration sensors. The IS220PVIBH1A features thirteen channels dedicated to processing input from these sensors, making it a highly capable device for multi-point vibration monitoring. This allows for simultaneous tracking of multiple aspects of machine health, enabling operators to identify and respond to potential issues before they lead to critical failures. The module’s ability to process data from both proximity and vibration sensors adds versatility, making it a key component in complex industrial setups where both types of monitoring are required.
With a common mode voltage minimum of 5 VDC, the IS220PVIBH1A is designed to provide stable and reliable signal processing. The module supports a range of frame rates—3.125, 6.25, 12.5, 25, 50, and 100 Hz—giving operators flexibility in selecting the appropriate frame rate based on their system’s requirements. These options enable the module to balance precision and performance, catering to different operational conditions and ensuring that data is collected at the most suitable frequency for each application.
Physically, the IS220PVIBH1A module has compact dimensions of 3.25 inches in height, 1.65 inches in width, and 4.78 inches in depth. This form factor makes it suitable for installation in a variety of system configurations, allowing for efficient use of space within control panels or racks. Its manageable size, combined with its powerful functionality, makes it an ideal choice for installations where space is limited but performance cannot be compromised.
The module is equipped with four LED indicators that provide real-time status information. These indicators include "Attention" (Attn), "Power" (Pwr), "Link," and "Transmit/Receive" (TxRx). These LEDs help operators quickly assess the operational status of the module, simplifying troubleshooting and maintenance tasks. The inclusion of clear status indicators minimizes downtime by allowing users to identify and address issues as soon as they arise.
In terms of power requirements, the IS220PVIBH1A provides -24 VDC power to the connected probes, with each transducer supporting a 12 mA load. This ensures that all connected sensors operate efficiently and consistently, providing accurate and reliable data to the control system. The module’s ability to power multiple sensors is critical in complex monitoring setups where numerous sensors are required to monitor various points on a piece of machinery or an entire system.
The module’s revisions include Rev. A, Rev. B, Rev. C, and Rev. D, reflecting its evolution and continued updates to meet industry standards and user requirements. Each revision introduces improvements and refinements, ensuring that the module remains up-to-date with the latest advancements in vibration monitoring technology.
The IS220PVIBH1A is identified by the functional acronym "PVIB," which indicates its specialized role in vibration monitoring and protection. This module is specifically designed to process vibration-related data, making it essential for applications in industries where rotating machinery such as turbines, compressors, and motors are prevalent. In such environments, vibration monitoring is crucial for predictive maintenance, helping to avoid costly equipment downtime by identifying potential problems before they lead to significant failures.
The data gathered by the IS220PVIBH1A can be integrated into larger control systems, allowing operators to make informed decisions based on real-time information. By delivering accurate vibration and proximity measurements, this module enables users to maintain the optimal performance of their machinery, reduce maintenance costs, and extend the service life of critical equipment.
In summary, the IS220PVIBH1A Vibration Control Module is a versatile and reliable component for industrial vibration and proximity monitoring. With compatibility for the Vibration Terminal Board (TVBA), support for thirteen input channels, multiple frame rate options, and robust power handling capabilities, it is well-suited for complex industrial environments that require precise and continuous monitoring of rotating machinery. Its compact size, comprehensive LED status indicators, and ability to operate across a wide temperature range make it an essential tool for maintaining system efficiency and preventing machinery failures.
