IS420UCSBH3A | General Electric UCSB Controller Module

Description

The IS420UCSBH3A UCSB Controller Module is another variant of the UCSB controller within the Mark VIe Series manufactured by General Electric. Identified as a Mark VIe or MarkStat Controller in the GEH-6725 Mark VIe and Mark VIeS Controls Equipment HazLoc Instruction Guide, this controller is powered by a 1200 MHz EP80579 Intel Microprocessor.

Similar to the UCSC controller in the Mark VIe Series, albeit with different hardware forms, the IS420UCSBH3A shares nearly identical software configurations with its counterpart. Noteworthy features of this controller include the absence of a battery and fan, as well as the elimination of required jumper settings.

Technical Specifications

Information About IS420UCSBH3A

The General Electric IS420UCSBH3A is a high-performance control system module designed to meet the demanding needs of industrial automation. This module, also referred to by its functional abbreviation UCSB, is a versatile and robust solution for managing complex industrial processes. It integrates advanced processing capabilities with a durable design, ensuring reliable operation in a wide range of environments.

The IS420UCSBH3A is equipped with a 1200 MHz EP80579 Intel processor, providing powerful computing performance for real-time control and data processing tasks. This high-speed processor ensures that the module can handle intensive computational workloads, making it suitable for applications that require quick and precise control responses.

The module operates within an input voltage range of 24/28 VDC, making it compatible with standard industrial power supplies. This flexibility in power requirements ensures that the IS420UCSBH3A can be easily integrated into existing systems without the need for extensive modifications.

One of the notable features of the IS420UCSBH3A is its ability to support wire sizes ranging from 28 to 16 AWG. This range accommodates various wiring requirements, providing versatility in how the module can be connected within a control system. Whether for signal connections or power delivery, the module's wiring capabilities ensure robust and reliable electrical connections.

The IS420UCSBH3A is designed to operate within a temperature range of 0 to 65°C, making it suitable for use in diverse industrial environments. This wide operating temperature range ensures that the module can maintain its performance and reliability even under extreme conditions, from cooler controlled environments to warmer industrial settings.

Physically, the module measures H 6.4 in x W 8.1 in x D 1.4 in and weighs approximately 2.9 lbs. These dimensions and weight make it a compact yet powerful addition to any control system. Its compact size allows for easy installation in control cabinets or on DIN rails, maximizing space efficiency without sacrificing performance.

Manufactured by General Electric, the IS420UCSBH3A adheres to the high standards of quality and reliability that GE is known for. The module's robust construction and advanced features ensure long-term durability and consistent performance, reducing the need for frequent maintenance and enhancing system uptime.

In summary, the GE IS420UCSBH3A control system module is a versatile and powerful solution for industrial automation. Its high-speed 1200 MHz EP80579 Intel processor, flexible input voltage, support for various wire sizes, and wide operating temperature range make it an ideal choice for demanding industrial applications. Its compact dimensions and reliable construction further enhance its suitability for integration into modern control systems. This module represents a reliable and efficient solution for enhancing the performance and reliability of industrial automation systems, ensuring optimal control and data processing capabilities in a compact form factor.
