IS5604-01 | Cognex Insight 5000 Line Scan Vision System 256MB

Description

The Cognex IS5604-01 is a line scan vision system from the Insight 5000 series. It features 256MB of memory and is designed for use in industrial machine vision applications. The system provides high-resolution imaging and processing capabilities for inspection, measurement, and identification tasks. It is suitable for environments requiring reliable, automated visual inspection solutions.

Technical Specifications

Information About IS5604-01

The Cognex IS5604-01 is a high-performance vision system designed for advanced industrial automation and machine vision applications. Part of the Camera & Vision category, this system falls under the subcategory of Vision System Assembly, making it a crucial component for tasks requiring precise image capture and analysis in real-time. The IS5604-01 offers robust and reliable functionality, specifically engineered to handle high-resolution imaging and fast processing, making it suitable for demanding inspection, measurement, and identification tasks in industrial environments.

The IS5604-01 features an 8.4 MP image sensor, providing a pixel resolution of 1024 x 8192 pixels. This high resolution ensures that the vision system captures exceptionally detailed images, making it ideal for applications that require accurate image analysis, such as quality control, product inspection, and barcode reading. The high-resolution capability allows for clear visualization of even the smallest details, ensuring that any anomalies or defects are detected with precision.

Operating at a frame rate of 44000 Hz, the IS5604-01 is capable of high-speed image capture, allowing it to process large amounts of data quickly and efficiently. This makes it particularly well-suited for use in high-speed production lines where rapid processing and real-time decision-making are critical. The fast frame rate ensures that the system can keep up with the pace of automated processes, capturing every detail without missing crucial information, even in dynamic environments.

The IS5604-01 operates on a 24 VDC power supply, which is standard in industrial applications, ensuring compatibility with most automation setups. This voltage level provides stable and reliable power to the vision system, ensuring continuous operation even in demanding conditions. The 24 VDC input also contributes to the system’s energy efficiency, making it a practical choice for extended operational periods.

For communication and data transfer, the IS5604-01 is equipped with Gigabit Ethernet connectivity. The high-speed Ethernet interface allows for fast and efficient data transmission between the vision system and the connected control systems or processing units. This ensures that large volumes of data, such as high-resolution images and analysis results, are transmitted rapidly, minimizing any delays in the production process. The system is fitted with an 8-pin M12 Ethernet connector, providing a secure and reliable connection in industrial environments where durability and resilience to external factors are essential.

In addition to the Ethernet connector, the IS5604-01 also features an 8-pin M12 breakout connector. This breakout connector provides additional flexibility, allowing the system to interface with various external devices, sensors, or control systems. The availability of a breakout connection expands the system’s integration capabilities, making it adaptable to a wide range of industrial applications where multiple data sources need to be processed simultaneously.

For serial communication, the IS5604-01 is equipped with an RS-232C connection, which is a standard interface for connecting peripheral devices, such as computers or other control systems. The RS-232C connection provides a reliable and established method of communication for transmitting data between the vision system and other devices, further enhancing the system’s versatility in industrial automation environments.

The IS5604-01 is specifically designed to operate in harsh industrial settings, with robust connectors and interfaces that ensure reliability under challenging conditions. Its rugged design and high performance make it an essential tool for industries such as manufacturing, automotive, electronics, and logistics, where precise vision inspection and fast data processing are critical to maintaining high standards of quality and efficiency.

In summary, the Cognex IS5604-01 vision system is a highly capable and versatile solution for advanced machine vision applications. With an 8.4 MP resolution, 44000 Hz frame rate, and Gigabit Ethernet connectivity, it provides high-speed, high-resolution image capture and processing, making it ideal for complex industrial tasks. The inclusion of an 8-pin M12 Ethernet connector, an 8-pin M12 breakout connector, and an RS-232C interface ensures that the system can be integrated seamlessly into a variety of automation environments. Operating on a 24 VDC power supply, the IS5604-01 delivers reliable performance in demanding industrial conditions, making it an excellent choice for industries that require accurate, real-time visual inspection and processing solutions.
