J9147A | HP Networking Gigabit Network Switch
- Regular price
- $1,542.00
- Sale price
- $1,542.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: J9147A
Description
HP J9147A is a 24-port Gigabit Ethernet managed switch from the HP 2910al Series. It features advanced Layer 2 and static Layer 3 routing, four dual-personality uplink ports, and supports stacking and high availability.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | HP Networking |
| Category |
Networking Hardware
|
| Part Number | J9147A |
| Subcategory |
Managed Network Switches
|
| Device Type | Switch - Managed - Stackable |
| Enclosure Type | External - 1u |
| Processor | 2 X Arm Arm1156t2-s : 515 Mhz |
| RAM | 512 Mb Sdram |
| Flash Memory | 4 Mb Flash |
| Voltage | 100-127/200-240 V |
| Current | 2.1/1.1 A |
| Idle Power | 64 W |
| Power Consumption | 105 W |
| Frequency | 50/60 Hz |
| Maximum Heat Dissipation | 376 kJ/hr (356 BTU/hr) |
| Operating Temperature | 0º C to 55º C (32º F to 131º F) |
| Operating Relative Humidity | 15% to 95% @ 40º C (104º F), non-condensing |
| Non-operating/Storage Temperature | -40º C to 70º C (-40º F to 158º F) |
| Non-operating/Storage Relative Humidity | 15% to 95% @ 65º C (149º F), non-condensing |
| Altitude | Up to 3 km (10,000 ft) |
| Acoustic | Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779 |
| Dimensions(d)*(w)*(h) | 36.58 x 44.25 x 4.4 cm (14.4 x 17.42 x 1.73 in) (1U height) |
| Weight | 5.08 kg (11.2 lb) |
Information About J9147A
The HP J9147A is a 48-port Layer 3 managed Gigabit Ethernet switch from the HP ProCurve 2910al Series. It offers high-performance switching with advanced features suitable for enterprise edge and branch office deployments.
Key Features:
-
Ports: 44 × 10/100/1000 Mbps RJ-45 ports, 4 dual-personality ports (RJ-45 or SFP)
-
Uplink Interfaces: Supports up to 4 optional 10GbE ports (CX4 and/or SFP+)
-
Switching Capacity: 176 Gbps
-
Throughput: Up to 131 million packets per second (Mpps)
-
Routing Capabilities: Static and RIP (v1 and v2) routing
-
Stacking: Supports stacking of up to 16 units with single IP address management
-
Management: Managed via CLI, web browser, SNMP (v1, v2c, v3), Telnet, and out-of-band serial console
-
Security Features: IEEE 802.1X, RADIUS, TACACS+, ACLs, SSH, SSL, and port security
-
Quality of Service (QoS): Supports traffic prioritization with 8 queues per port
-
IPv6 Support: Dual-stack IPv4/IPv6, MLD snooping, and IPv6 management features
-
Form Factor: 1U rack-mountable
-
Power Supply: Internal AC power supply (100–240V, 50/60 Hz)
-
Operating Temperature: 32°F to 131°F (0°C to 55°C)
-
Operating Humidity: 15% to 95% non-condensing
This switch is ideal for organizations seeking a scalable and reliable solution for high-performance network connectivity with advanced Layer 3 features.
Description
HP J9147A is a 24-port Gigabit Ethernet managed switch from the HP 2910al Series. It features advanced Layer 2 and static Layer 3 routing, four dual-personality uplink ports, and supports stacking and high availability.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | HP Networking |
| Category |
Networking Hardware
|
| Part Number | J9147A |
| Subcategory |
Managed Network Switches
|
| Device Type | Switch - Managed - Stackable |
| Enclosure Type | External - 1u |
| Processor | 2 X Arm Arm1156t2-s : 515 Mhz |
| RAM | 512 Mb Sdram |
| Flash Memory | 4 Mb Flash |
| Voltage | 100-127/200-240 V |
| Current | 2.1/1.1 A |
| Idle Power | 64 W |
| Power Consumption | 105 W |
| Frequency | 50/60 Hz |
| Maximum Heat Dissipation | 376 kJ/hr (356 BTU/hr) |
| Operating Temperature | 0º C to 55º C (32º F to 131º F) |
| Operating Relative Humidity | 15% to 95% @ 40º C (104º F), non-condensing |
| Non-operating/Storage Temperature | -40º C to 70º C (-40º F to 158º F) |
| Non-operating/Storage Relative Humidity | 15% to 95% @ 65º C (149º F), non-condensing |
| Altitude | Up to 3 km (10,000 ft) |
| Acoustic | Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779 |
| Dimensions(d)*(w)*(h) | 36.58 x 44.25 x 4.4 cm (14.4 x 17.42 x 1.73 in) (1U height) |
| Weight | 5.08 kg (11.2 lb) |
Information About J9147A
The HP J9147A is a 48-port Layer 3 managed Gigabit Ethernet switch from the HP ProCurve 2910al Series. It offers high-performance switching with advanced features suitable for enterprise edge and branch office deployments.
Key Features:
-
Ports: 44 × 10/100/1000 Mbps RJ-45 ports, 4 dual-personality ports (RJ-45 or SFP)
-
Uplink Interfaces: Supports up to 4 optional 10GbE ports (CX4 and/or SFP+)
-
Switching Capacity: 176 Gbps
-
Throughput: Up to 131 million packets per second (Mpps)
-
Routing Capabilities: Static and RIP (v1 and v2) routing
-
Stacking: Supports stacking of up to 16 units with single IP address management
-
Management: Managed via CLI, web browser, SNMP (v1, v2c, v3), Telnet, and out-of-band serial console
-
Security Features: IEEE 802.1X, RADIUS, TACACS+, ACLs, SSH, SSL, and port security
-
Quality of Service (QoS): Supports traffic prioritization with 8 queues per port
-
IPv6 Support: Dual-stack IPv4/IPv6, MLD snooping, and IPv6 management features
-
Form Factor: 1U rack-mountable
-
Power Supply: Internal AC power supply (100–240V, 50/60 Hz)
-
Operating Temperature: 32°F to 131°F (0°C to 55°C)
-
Operating Humidity: 15% to 95% non-condensing
This switch is ideal for organizations seeking a scalable and reliable solution for high-performance network connectivity with advanced Layer 3 features.
