JACE-8000 | Niagara Controller
- Regular price
- $2,399.00
- Sale price
- $2,399.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: JACE-8000
Description
The JACE-8000 is a powerful and compact embedded IoT controller designed to manage and integrate various building automation systems. With built-in support for data logging, alarming, scheduling, and web-based graphical displays, it enables efficient supervisory control over multiple devices and subsystems. Its Wi-Fi and Ethernet capabilities provide seamless remote access for real-time system management.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Niagara |
| Category |
Controllers
|
| Part Number | JACE-8000 |
| Subcategory | IoT Building Automation Controllers |
| Processor | TI AM3352, 1000MHz ARM® Cortex™-A8 |
| Memory |
1GB DDR3 SDRAM |
| Storage | 4GB MicroSD (2GB user available) |
| Communication | Wi-Fi 802.11 a/b/g/n, RS-485, Ethernet (2x 10/100MB) |
| USB Interface | USB Type A (Backup & Restore) |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5%–95% RH non-condensing |
| Power Supply | 24VAC (24VA) or 24VDC (24W) |
| Mounting Clearance | 1.5" (38mm) on sides, 3" (76mm) at bottom |
| Expansion Modules Supported | Up to 4 |
| Compliance/Certifications | UL 916, CE, FCC, RCM, CSA, RoHS |
| MTTF | 10+ years |
| Weight | 1.3 lbs (0.59 kg) |
Information About JACE-8000
The JACE-8000 is part of the Niagara Framework® family, engineered for scalable building integration and analytics. The unit features a 1000MHz ARM® Cortex™-A8 processor, 1GB DDR3 SDRAM, and built-in support for Niagara 4.1 and later versions. It offers extensive I/O and communication options including dual RS-485 ports, dual Ethernet ports, USB backup and restore functionality, and Wi-Fi (802.11 a/b/g/n). The controller complies with multiple industry certifications (UL, CE, FCC, CSA) and operates reliably in demanding environments with an extended temperature range of -20°C to 60°C. Its high MTTF rating of 10+ years ensures dependable long-term use in both small- and large-scale building automation systems.
Key Features:
- Powerful Performance: Equipped with a 1000MHz ARM Cortex-A8 processor and 1GB DDR3 memory to handle complex integration and control tasks.
- Flexible Connectivity: Supports Wi-Fi (WAP or Client mode), USB type A, dual RS-485 ports, and two 10/100MB Ethernet ports for robust system interfacing.
- Expandable Architecture: Allows connection of up to four expansion modules for customized I/O configurations and system scalability.
- Industrial-Grade Durability: Operating temperature from -20°C to 60°C and compliance with ASTM D4169 vibration standards ensure reliability in rugged conditions.
- Integrated Security: Features secure boot, WPA2 Wi-Fi encryption, and compliance with industry security standards for safe network operation.
- Universal Mounting Options: Supports easy panel or enclosure mounting with defined clearance for optimal antenna performance.
The JACE-8000 enables streamlined integration of building systems, making it ideal for multi-site enterprise installations and analytics-driven facilities management.
