JDA262502 | Square D 250A 2-Pole 600V Thermal Magnetic I-Line Molded Case Circuit Breaker
- Regular price
- $2,399.00
- Sale price
- $2,399.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: JDA262502
Description
The Square D JDA262502 is a 2-pole thermal magnetic molded case circuit breaker designed to provide reliable protection for electrical circuits rated up to 250 amps and 600 VAC. It offers a 14 kA interrupting capacity at 600V, ensuring dependable performance in demanding industrial and commercial applications. The unit features an I-Line bracket mounting system for secure, efficient installation in switchboards and panel assemblies.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Protection |
| Part Number | JDA262502 |
| Subcategory | Molded Case Circuit Breaker |
| Series | PowerPacT J |
| Frame Type | JDA (J-Frame) |
| Amperage Rating | 250 A |
| Voltage Rating | 600 VAC |
| Poles | 2 |
| Trip Unit Type | Thermal Magnetic |
| Interrupting Rating | 14 kAIC @ 600 VAC |
| Mounting Type | I-Line Bracket |
| Connection Type | I-Line Line Side / Lug Load Side |
| Protection Type | Overload & Short Circuit |
| Continuous Current Rating | 80% |
| Magnetic Tripping Current | 2500 A |
| Insulation Voltage (Ui) | 750 V (IEC 60947-2) |
| Impulse Withstand Voltage (Uimp) | 8 kV |
| Operating Frequency | 50/60 Hz |
| Approvals | UL, CSA, CE, NOM, IEC |
| Operating Temperature | -25°C to 70°C |
| Storage Temperature | -50°C to 85°C |
| Dimensions (H × W × D) | 7.5 × 4.09 × 3.4 in |
| Weight | 5.3 lb (2.4 kg) |
Information About JDA262502
The JDA262502 is part of the Square D PowerPacT J-Frame series, known for compact molded case construction and advanced circuit protection. It integrates dual-break rotating contacts to minimize peak current during fault conditions and enhance arc interruption efficiency. Designed for use in I-Line systems, it includes I-Line connections on the line side and mechanical lugs on the load side for simplified installation. Certified to UL, CSA, CE, NOM, and IEC standards, this breaker is ideal for industrial, commercial, and residential electrical distribution systems requiring high reliability and performance.
Key Features:
- Rated Current: 250 Amps — Supports medium-power loads with consistent current protection.
- Voltage Rating: 600 VAC — Suitable for a wide range of AC power distribution systems.
- Interrupting Capacity: 14 kAIC @ 600V — Provides strong short-circuit protection performance.
- Trip Unit: Thermal Magnetic — Combines long-time overload and instantaneous short-circuit trip functions.
- Mounting Type: I-Line Bracket — Enables quick, secure installation and easy removal in I-Line panels.
- Dual-Break Rotating Contacts: Reduces peak current and improves arc interruption efficiency.
- Certified Standards: UL, CSA, CE, NOM, IEC — Meets international compliance and safety requirements.
- Operating Temperature Range: -25°C to 70°C — Ensures reliable performance under wide environmental conditions.
The JDA262502 delivers the reliability and precision required for stable, high-performance power protection in modern electrical systems.
