Product Description P/N: JDA36150

Description / Specifications

Description

The JDA36150 Circuit Breaker, part of the PowerPacT J series, is designed to safeguard electrical systems from damage caused by overloads and short circuits. Featuring a 3-pole configuration and a current rating of 150A, this circuit breaker operates at 600VAC with a breaking capacity of 14kA.

Equipped with thermal magnetic circuit protection, the PowerPacT J-Frame breaker ensures reliable performance in various applications. It is furnished with dual-break rotating contacts, reducing peak current during short circuit faults for enhanced safety.



Technical Specifications

Part #

JDA36150

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Line Rated Current

150 A

Number of Poles

3P

Control Type

Toggle

Breaking capacity code

D

[Ue] rated operational voltage

600 V AC 50/60 Hz

Network Frequency

50/60 Hz

[Uimp] rated impulse withstand voltage

8 kV

Trip unit technology

Thermal-magnetic

Magnetic tripping current

1750 A

Magnetic hold current

750 A

Continuous current rating

80 %

[Ui] rated insulation voltage

750 V

Suitability for isolation

Yes

Utilisation category

Category A

AWG gauge

AWG 4...AWG 4/0 aluminium/copper terminal

Local signalling

Switched off (OFF), 1 trip indicator green

Mounting mode

I-Line bracket

Mounting Support

Bracket

Terminal identifier

AL175JD

Long time pick-up adjustment range

0.25...1 x In

Mounting Height

4.5 in (114.30 mm)

Tightening torque

221.27 lbf.in (25 N.m), 0.04…0.15 in² (25…95 mm²) (AWG 4...AWG 4/0)

Power wire stripping length

0.98 in (25 mm)

Height

7.52 in (191 mm)

Width

4.09 in (104 mm)

Depth

3.39 in (86 mm)

Net Weight

5.29 lb(US) (2.4 kg)

Phase connection

ABC

Communication interface

Modbus

Circuit breaker application

HACR rated



Information About JDA36150


The JDA36150 circuit breaker, part of the PowerPacT J series, is engineered to safeguard electrical systems against damage stemming from overloads and short circuits. PowerPacT J-Frame circuit breakers are versatile, offering a choice between thermal magnetic or MicroLogic electronic trip protection units. This specific circuit breaker delivers thermal magnetic circuit protection, boasting a robust breaking capacity of 14kA at 600VAC.

All PowerPacT J-Frame circuit breakers feature dual-break rotating contacts, a design element that effectively mitigates peak current levels during short circuit faults. Moreover, these circuit breakers are equipped with an integral push-to-trip button integrated into the cover, allowing for manual tripping when necessary.

Available in both 2 and 3-pole unit mount configurations, as well as I-Line constructions, PowerPacT J circuit breakers offer flexibility to suit various installation needs. Notably, PowerPacT J I-Line circuit breakers are designed specifically for I-Line applications, facilitating straightforward installation and removal.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
Description / Specifications

Description

The JDA36150 Circuit Breaker, part of the PowerPacT J series, is designed to safeguard electrical systems from damage caused by overloads and short circuits. Featuring a 3-pole configuration and a current rating of 150A, this circuit breaker operates at 600VAC with a breaking capacity of 14kA.

Equipped with thermal magnetic circuit protection, the PowerPacT J-Frame breaker ensures reliable performance in various applications. It is furnished with dual-break rotating contacts, reducing peak current during short circuit faults for enhanced safety.



Technical Specifications

Part #

JDA36150

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Line Rated Current

150 A

Number of Poles

3P

Control Type

Toggle

Breaking capacity code

D

[Ue] rated operational voltage

600 V AC 50/60 Hz

Network Frequency

50/60 Hz

[Uimp] rated impulse withstand voltage

8 kV

Trip unit technology

Thermal-magnetic

Magnetic tripping current

1750 A

Magnetic hold current

750 A

Continuous current rating

80 %

[Ui] rated insulation voltage

750 V

Suitability for isolation

Yes

Utilisation category

Category A

AWG gauge

AWG 4...AWG 4/0 aluminium/copper terminal

Local signalling

Switched off (OFF), 1 trip indicator green

Mounting mode

I-Line bracket

Mounting Support

Bracket

Terminal identifier

AL175JD

Long time pick-up adjustment range

0.25...1 x In

Mounting Height

4.5 in (114.30 mm)

Tightening torque

221.27 lbf.in (25 N.m), 0.04…0.15 in² (25…95 mm²) (AWG 4...AWG 4/0)

Power wire stripping length

0.98 in (25 mm)

Height

7.52 in (191 mm)

Width

4.09 in (104 mm)

Depth

3.39 in (86 mm)

Net Weight

5.29 lb(US) (2.4 kg)

Phase connection

ABC

Communication interface

Modbus

Circuit breaker application

HACR rated



Information About JDA36150


The JDA36150 circuit breaker, part of the PowerPacT J series, is engineered to safeguard electrical systems against damage stemming from overloads and short circuits. PowerPacT J-Frame circuit breakers are versatile, offering a choice between thermal magnetic or MicroLogic electronic trip protection units. This specific circuit breaker delivers thermal magnetic circuit protection, boasting a robust breaking capacity of 14kA at 600VAC.

All PowerPacT J-Frame circuit breakers feature dual-break rotating contacts, a design element that effectively mitigates peak current levels during short circuit faults. Moreover, these circuit breakers are equipped with an integral push-to-trip button integrated into the cover, allowing for manual tripping when necessary.

Available in both 2 and 3-pole unit mount configurations, as well as I-Line constructions, PowerPacT J circuit breakers offer flexibility to suit various installation needs. Notably, PowerPacT J I-Line circuit breakers are designed specifically for I-Line applications, facilitating straightforward installation and removal.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
