JDA36225 | Schneider Electric Circuit Breaker
- Regular price
- $1,099.00
- Sale price
- $1,099.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: JDA36225
Description
The JDA36225 is a 225A, 3-pole circuit breaker from Eaton's PowerPacT J series, designed to safeguard electrical systems against overloads and short circuits. Featuring thermal magnetic trip technology, it offers a robust breaking capacity of 14kA at 600VAC. Equipped with dual-break rotating contacts to minimize peak current during short circuit faults, this circuit breaker includes an integral push-to-trip button for manual operation.
Technical Specifications
|
Part # |
JDA36225 |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker Range |
|
Product name |
PowerPact J |
|
Product or Component Type |
Circuit breaker |
|
Device Application |
Distribution |
|
In Rated Current |
225 A |
|
Number of Poles |
3P |
|
Control Type |
Toggle |
|
Breaking capacity code |
D |
|
Rated Operational Voltage (Ue) |
600 V AC 50/60 Hz IEC 60947-3 |
|
Network Frequency |
50/60 Hz |
|
Rated Impulse Withstand Voltage (Uimp) |
8 kV IEC 60947-2 |
|
Trip Unit Technology |
Thermal-magnetic |
|
Magnetic Tripping Current |
2250 A |
|
Magnetic Hold Current |
1125 A |
|
Continuous Current Rating |
80% |
|
Rated Insulation Voltage (Ui) |
750 V IEC 60947-2 |
|
Protection Type |
Overload protection, Short-circuit protection |
|
Suitability for Isolation |
Yes IEC 60947-2 |
|
Utilisation Category |
Category A |
|
AWG Gauge |
AWG 3/0...350 kcmil aluminium/copper terminals |
|
Local Signalling |
Switched off (OFF), 1 trip indicator green) |
|
Mounting Mode |
I-Line bracket) |
|
Mounting Support |
Bracket |
|
Terminal Identifier |
AL250JD |
|
Long Time Pick-Up Adjustment Range |
0.25...1 x In |
Information About JDA36225
The PowerPacT J-Frame circuit breaker, model JDA36225, is engineered to safeguard electrical systems against damage from overloads and short circuits. Available with both thermal magnetic and MicroLogic electronic trip protection units, this breaker offers thermal magnetic circuit protection specifically rated for a breaking capacity of 14kA at 600VAC.
Equipped with dual-break rotating contacts designed to mitigate peak current during short circuit faults, the PowerPacT J-Frame circuit breakers feature an integral push-to-trip button for manual operation located on the cover. These circuit breakers are adaptable for both 2 and 3-pole unit mount configurations as well as I-Line constructions, facilitating easy installation and removal in I-Line applications.
The JDA36225 unit is configured with I-Line terminations on the line side and mechanical lugs on the load side. It is specifically rated at 225A across its 3 poles, with a continuous current rating of 80% and an ABC phase connection.
