JG960A | HP Networking Managed Rack-Mountable Switch 24 Ports
- Regular price
- $914.00
- Sale price
- $914.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: JG960A
Description
The HP Networking JG960A is a high-performance managed Layer 3 network switch, engineered to meet the demands of modern enterprise networks. Offering robust switching capacity, flexible connectivity, and low power consumption, it’s tailored for scalable deployment in server rooms and enterprise core infrastructures.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | HP Networking |
| Category |
Managed Switches
|
| Part Number | JG960A |
| Subcatecory |
Enterprise Layer 3 Switches
|
| Form Factor |
Rack-mountable, 1U
|
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| Ports | 24x 10/100/1000Base-T, 2x SFP+, 2x 10G RJ-45 |
| Routing Table Size | 32 IPv4, 32 IPv6 entries |
| MAC Address Table | 16,384 entries |
| Input Voltage | 100–240V AC, 50/60 Hz |
| Maximum Power Consumption | 34 W |
| Operating Temperature | 0°C to 45°C |
| Relative Humidity | 10%–90% operating, 5%–95% storage |
| Altitude Tolerance | Up to 5,000 m |
| Acoustic Noise | 19.0 dB (low), 44.5 dB (high) |
| Dimensions (W x D x H) | 43.6 x 16 x 4.4 cm |
| Weight | 3 kg (6.61 lbs) |
Information About JG960A
The JG960A is a 24-port managed rack-mountable switch with Layer 3 capabilities, supporting both routing and switching at up to 128 Gbps capacity and a throughput rate of 95.2 Mpps. It includes 24 auto-negotiating RJ-45 Gigabit Ethernet ports, along with 2 SFP+ fixed 10G ports and 2 RJ-45 10GBASE-T uplinks, offering versatile connectivity options for aggregation and uplinks to high-speed backbones. Designed with dual-speed cooling fans and an energy-efficient footprint, this switch is optimized for quiet operation, with acoustic ratings ranging from 19.0 dB to 44.5 dB.
Key Features:
- Comprehensive Port Set: Equipped with 24x 10/100/1000Base-T Ethernet ports, 2x SFP+ ports, and 2x 1/10GBASE-T RJ-45 uplink ports, it offers high flexibility for network expansion and core integration.
- High Throughput and Switching Capacity: Achieves 95.2 Mpps throughput and 128 Gbps switching bandwidth, supporting performance-intensive routing and switching operations.
- Layer 3 Routing Capabilities: Enables static routing with 32 IPv4 and 32 IPv6 entries, providing intelligent traffic control and simplified network segmentation.
- Enterprise Reliability: Dual-speed fans manage acoustic output (as low as 19.0 dB), and the unit tolerates extreme conditions from -40°C to 70°C in non-operating states.
- Efficient Design: Consumes only 34W maximum power, making it suitable for environmentally conscious network environments.
The JG960A is a space-efficient, energy-saving managed switch that integrates well into demanding enterprise infrastructures and supports long-term scalability.
Description
The HP Networking JG960A is a high-performance managed Layer 3 network switch, engineered to meet the demands of modern enterprise networks. Offering robust switching capacity, flexible connectivity, and low power consumption, it’s tailored for scalable deployment in server rooms and enterprise core infrastructures.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | HP Networking |
| Category |
Managed Switches
|
| Part Number | JG960A |
| Subcatecory |
Enterprise Layer 3 Switches
|
| Form Factor |
Rack-mountable, 1U
|
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| Ports | 24x 10/100/1000Base-T, 2x SFP+, 2x 10G RJ-45 |
| Routing Table Size | 32 IPv4, 32 IPv6 entries |
| MAC Address Table | 16,384 entries |
| Input Voltage | 100–240V AC, 50/60 Hz |
| Maximum Power Consumption | 34 W |
| Operating Temperature | 0°C to 45°C |
| Relative Humidity | 10%–90% operating, 5%–95% storage |
| Altitude Tolerance | Up to 5,000 m |
| Acoustic Noise | 19.0 dB (low), 44.5 dB (high) |
| Dimensions (W x D x H) | 43.6 x 16 x 4.4 cm |
| Weight | 3 kg (6.61 lbs) |
Information About JG960A
The JG960A is a 24-port managed rack-mountable switch with Layer 3 capabilities, supporting both routing and switching at up to 128 Gbps capacity and a throughput rate of 95.2 Mpps. It includes 24 auto-negotiating RJ-45 Gigabit Ethernet ports, along with 2 SFP+ fixed 10G ports and 2 RJ-45 10GBASE-T uplinks, offering versatile connectivity options for aggregation and uplinks to high-speed backbones. Designed with dual-speed cooling fans and an energy-efficient footprint, this switch is optimized for quiet operation, with acoustic ratings ranging from 19.0 dB to 44.5 dB.
Key Features:
- Comprehensive Port Set: Equipped with 24x 10/100/1000Base-T Ethernet ports, 2x SFP+ ports, and 2x 1/10GBASE-T RJ-45 uplink ports, it offers high flexibility for network expansion and core integration.
- High Throughput and Switching Capacity: Achieves 95.2 Mpps throughput and 128 Gbps switching bandwidth, supporting performance-intensive routing and switching operations.
- Layer 3 Routing Capabilities: Enables static routing with 32 IPv4 and 32 IPv6 entries, providing intelligent traffic control and simplified network segmentation.
- Enterprise Reliability: Dual-speed fans manage acoustic output (as low as 19.0 dB), and the unit tolerates extreme conditions from -40°C to 70°C in non-operating states.
- Efficient Design: Consumes only 34W maximum power, making it suitable for environmentally conscious network environments.
The JG960A is a space-efficient, energy-saving managed switch that integrates well into demanding enterprise infrastructures and supports long-term scalability.
