JL357A | HP Networking SFP+ Switch
- Regular price
- $2,172.00
- Sale price
- $2,172.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: JL357A
Description
The HP JL357A is an HPE Aruba 3810M 24G SFP+ 1-slot Switch, offering 24 SFP+ ports for high-speed 10-Gigabit Ethernet connectivity.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | HP Networking |
| Category |
Networking Equipment
|
| Part Number | JL357A |
| Subcategory |
Managed Layer 3 Switches (SFP+/10GbE)
|
| Device Type | Switch - 48 Ports - Managed |
| Enclosure Type |
Desktop, Rack-Mountable, Wall-Mountable 1U
|
|
Ports
|
48 x RJ-45 Autosensing 10/100/1000 PoE+ Ports + 4x SFP+ 1/10GbE Ports + PHY-less |
|
PoE Budget
|
370 W |
|
MAC Address Table Size
|
16384 entries |
|
Encryption Algorithm
|
SSL |
|
Latency
|
1000 Mb Latency: < 3.8 µs, 10 Gbps Latency: < 1.6 µs |
|
Throughput
|
Up to 112 Mpps |
|
Switching Capacity
|
176 Gbps |
|
Processor
|
1 x Dual Core ARM Coretex A9 @ 1016 MHz |
|
RAM
|
1 GB DDR3 SDRAM |
|
Packet Buffer Size
|
12.38 MB 4.5MB Ingress/7.875MB Egress |
|
Flash Memory
|
4 GB eMMC |
|
Interfaces
|
48 x 1000Base-T RJ-45 PoE+, 4 x Gigabit / 10Gbit LAN SFP+, 1 x console RJ-45 management, 1 x micro-USB Type B management |
|
Input Voltage
|
100 - 127 / 200 - 240 VAC (50/60 Hz), Rated |
|
Power Consumption
|
459 W (maximum) |
|
Heat Dissipation
|
1566 BTU/hr (1652.13 kJ/hr) |
|
Operating Temperature Range
|
32 °F to 113 °F |
|
Storage Temperature Range
|
-40 °F to 158 °F |
|
Humidity Range Operating
|
15 - 95% (non-condensing) |
|
Humidity Range Storage
|
15 - 90% (non-condensing) |
|
Weight
|
9.83 lbs |
Information About JL357A
The HP JL357A, part of the HPE Aruba 3810M Series, is a high-performance Layer 3 modular network switch designed for enterprise edge and aggregation layer deployments. It features 24 SFP+ ports, providing full 10-Gigabit Ethernet support for high-density fiber connectivity. This switch combines speed, scalability, and enterprise-grade security with Aruba’s intelligent management and flexibility, making it ideal for modern campus and data-intensive network environments.
Key Features:
Port Configuration:
-
24 x SFP+ (10G) ports for high-speed fiber uplinks and aggregation
-
1 modular slot for optional expansion modules (10G/40G support)
-
Ideal for high-throughput edge and distribution switching
Performance and Routing:
-
Layer 3 switch with support for static routing, OSPF, BGP, and RIP
-
Switching capacity: Up to 598 Gbps
-
Throughput: Up to 443 Mpps
-
Advanced routing protocols and dynamic IP routing support
Flexibility and Scalability:
-
Modular design allows for uplink and stacking module customization
-
Optional backplane stacking with up to 336 Gbps stack bandwidth
-
Stack up to 10 switches for simplified management and resilience
Security and QoS:
-
Role-based access control (RBAC)
-
MACsec encryption, 802.1X network access control, RADIUS, and TACACS+
-
Dynamic segmentation with ClearPass Policy Manager
-
Intelligent traffic prioritization and congestion management
Management and Monitoring:
-
Powered by ArubaOS
-
Managed via Aruba AirWave, Aruba Central, or CLI
-
SNMP v1/v2/v3, RMON, sFlow support
-
Supports Zero Touch Provisioning (ZTP)
Energy Efficiency:
-
Energy-efficient Ethernet (EEE) and fan speed management
-
Supports internal and external redundant power supplies
The HP JL357A (Aruba 3810M 24G SFP+ 1-slot) switch is a scalable, high-density fiber aggregation switch built for modern enterprise environments. With full 10G SFP+ connectivity, Layer 3 routing, and modular uplink options, it provides robust performance, secure access, and centralized management for evolving campus and data-driven networks. Its flexible design and stacking capabilities make it a future-ready choice for organizations seeking resilient, high-speed network infrastructure.
