Johnson Controls VA9208-BGA-3 24V On/Off Spring Return Ball Valve Actuator
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VA9208-BGA-3
Description
The Johnson Controls VA9208-BGA-3 is an electric spring return ball valve actuator designed for two-position control of VG1000 Series 1-1/4, 1-1/2, and 2-inch ball valves in HVAC systems. It operates with 24 VAC power and provides 70 lb-in of torque with a 90° stroke. The actuator uses electronic control and reduces power consumption while holding position.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Johnson Controls |
| Category | HVAC Valve Actuators |
| Part Number | VA9208-BGA-3 |
| Subcategory | On/Off Spring Return Ball Valve Actuators |
| Product Series | VA9208 |
| Actuator Type | Electric Ball Valve Actuator |
| Control Signal | Two Position / On-Off |
| Supply Voltage | 24 VAC |
| Torque | 70 in-lb |
| Fail-Safe Mode | Spring Return |
| Stroke | 90° |
| Run Time | 60 seconds |
| Motor Type | DC Brush Motor |
| Control Method | Analog Electronics |
| Manual Operation | No |
| Valve Compatibility | Johnson Controls VG1000 Series |
| Valve Size | 1-1/4, 1-1/2, and 2 in. |
| Ambient Temperature | Up to 140°F |
| Approvals | CE, UL |
| Weight | 3.4 lbs |
Information About VA9208-BGA-3
The VA9208-BGA-3 belongs to the VA9208 series of direct-mount electric actuators developed for Johnson Controls VG1000 ball valves. Its DC brush motor is controlled by analog electronics and can remain stalled at any point within its rotation without mechanical end switches. The spring return mechanism provides a defined fail-safe position when actuator power is removed. The actuator is intended for two-position control from a manual switch, controller, fan motor contactor auxiliary switch, or similar control device.
Key Features:
- 24 VAC Operation: Designed for 24 VAC power in HVAC valve control applications.
- On/Off Control: Provides two-position control for compatible VG1000 Series ball valves.
- 70 lb-in Torque: Delivers 70 lb-in of actuator torque for valve operation.
- Spring Return: Provides mechanical fail-safe positioning when power is removed.
- 90° Stroke: Provides 90 degrees of actuator rotation for ball valve positioning.
- Electronic Stall Control: Allows the motor to stall within its rotation range without mechanical end switches.
- Reduced Holding Power: Electronic control reduces power consumption while maintaining the commanded position.
- VG1000 Compatibility: Designed for Johnson Controls VG1000 1-1/4, 1-1/2, and 2-inch ball valves.
The VA9208-BGA-3 delivers the reliability and precision required for two-position spring return HVAC ball valve control.
