KDB2150 | Eaton Cutler-Hammer Series C K-Frame Molded Case Circuit Breaker 150A 2-Pole 600V
- Regular price
- $1,395.00
- Sale price
- $1,395.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: KDB2150
Description
The Eaton Cutler-Hammer KDB2150 is a Series C molded case circuit breaker designed to provide reliable overload and short-circuit protection in industrial electrical systems. This two-pole breaker is rated at 150 A and operates at up to 600 VAC and 250 VDC with fixed thermal and fixed magnetic trip characteristics. The KDB2150 supports consistent circuit protection where high interrupting capacity and durable construction are required.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | KDB2150 |
| Subcategory | Molded Case / 2-Pole |
| Series | Series C |
| Breaker Type | KDB |
| Frame Type | K-Frame |
| Number of Poles | 2 |
| Amperage Rating | 150 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Trip Unit Type | Fixed Thermal / Fixed Magnetic |
| Protection Functions | LI – Long-Time and Instantaneous |
| Interrupt Rating | 65 kA at 240 V AC / 35 kA at 480 V AC |
| Frequency Rating | 50/60 Hz |
| Terminal Configuration | Line and Load |
| Terminal Material | Aluminum |
| Product Length / Depth | 4.1 in |
| Product Height | 5.5 in |
| Product Width | 5.5 in |
| Product Weight | 11.5 lb |
Information About KDB2150
The KDB2150 is part of Eaton’s Cutler-Hammer Series C lineup and is built on a K-frame platform for industrial-grade performance. It incorporates fixed thermal and magnetic trip elements that deliver predictable response to sustained overloads and instantaneous short-circuit conditions. The breaker is configured as a two-pole device, supporting protection of single-phase and select distribution circuits. Its aluminum terminal construction and complete breaker design allow use on both line and load sides in demanding electrical environments.
Key Features:
- Series C K-Frame Construction: Engineered for durability and stable operation in industrial power distribution systems.
- Fixed Thermal and Magnetic Trip Mechanism: Provides consistent overload and short-circuit protection without adjustable settings.
- 150 Amp Current Rating: Suitable for feeder and distribution circuits requiring higher current capacity.
- Two-Pole Configuration: Enables coordinated protection and isolation of both conductors in applicable systems.
- High Interrupting Capacity: Rated up to 65 kA at 240 V AC to safely interrupt severe fault currents.
- Dual Voltage Capability: Operates at 600 VAC and 250 VDC for flexibility across AC and DC applications.
- Aluminum Line and Load Terminals: Designed to withstand mechanical stress while maintaining secure electrical connections.
The KDB2150 delivers the reliability and precision required for effective circuit protection in Eaton Cutler-Hammer Series C industrial electrical distribution systems.
