Keyence CA-DC60E LED Light Expansion Unit for Machine Vision Systems
- Regular price
- $1,299.00
- Sale price
- $1,299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CA-DC60E
Description
The Keyence CA-DC60E is an LED light expansion unit designed to control illumination for compatible machine vision systems. It provides two lighting channels, constant-current control, and 1,024-step digital intensity adjustment to support consistent image capture during automated inspection and measurement.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Keyence |
| Category | Machine Vision |
| Part Number | CA-DC60E |
| Subcategory | LED Lighting Controllers |
| Series | CA-D |
| Unit Type | LED light expansion unit |
| Control Method | Constant-current control |
| Lighting Channels | 2 |
| Intensity Adjustment | 1,024 digital levels |
| Connector | 12-pole dedicated connector |
| Synchronization | Camera trigger and shutter |
| Response Time | ≤1 ms |
| Status Indicators | Power and lighting LEDs |
| Power Supply | 24 VDC (+25%/-20%) |
| Current Consumption | 5.7 A at 19.2 VDC; 4.6 A at 24 VDC |
| Mounting | DIN rail or bottom |
| Operating Temperature | 0 to +45°C (DIN rail); 0 to +40°C (bottom) |
| Humidity | Up to 85% RH, non-condensing |
| Weight | 500 g |
Information About CA-DC60E
The CA-DC60E belongs to the Keyence CA-D series of machine vision lighting control equipment. It connects compatible LED lighting units through a dedicated 12-pole connector and supports synchronization with camera triggers and shutter signals. Its brightness settings can be adjusted through the associated controller, allowing illumination to be configured for different inspection conditions. The unit supports DIN rail or bottom mounting and includes separate LED indicators for power and lighting status on each channel.
Key Features:
- Dual-Channel Control: Supports two LED lighting channels through a dedicated 12-pole connector.
- Constant-Current Control: Regulates lighting current to maintain consistent illumination.
- Digital Intensity Adjustment: Provides 1,024 brightness levels selectable through the controller.
- Camera Synchronization: Supports camera trigger and shutter synchronization.
- Fast Response: Lighting control response time of 1 ms or less.
- Flexible Mounting: Supports DIN rail or bottom mounting.
- Industrial Power Input: Operates from a nominal 24 VDC supply with specified voltage tolerance.
The CA-DC60E delivers the reliability and precision required for machine vision illumination, automated optical inspection, and industrial image-processing systems.
