Keyence FD-XA1 DIN Rail Flow Sensor Controller for Industrial Automation
- Regular price
- $465.00
- Sale price
- $465.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FD-XA1
Description
The Keyence FD-XA1 is a DIN rail-mounted controller designed for use with the FD-X series clamp-on micro flow sensors. It processes flow measurement data, displays instantaneous and accumulated flow values, and provides configurable outputs for industrial process monitoring, liquid dispensing, and automated flow control.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Keyence |
| Category | Flow Measurement |
| Part Number | FD-XA1 |
| Subcategory | Flow Sensor Controllers |
| Controller Type | DIN rail-mounted main unit |
| Display | 4-digit LED, OLED, status indicators |
| Response Time | 50 ms–60 s |
| Detection Modes | Flow, area, pulse, accumulation, shot |
| Output Type | NPN/PNP open collector |
| Analog Output | 4–20 mA or 0–20 mA |
| Max. Output Voltage | 30 VDC |
| Max. Output Current | 50 mA/channel |
| Power Supply | 20–30 VDC |
| Power Consumption | 195 mA max., excluding load |
| Communication | IO-Link v1.1, COM2 |
| Expansion Capacity | Up to 7 units |
| Memory | EEPROM |
| Storage Interval | Every 10 seconds |
| USB Interface | USB 2.0 |
| Operating Temperature | -10 to +50°C |
| Humidity | 35–85% RH, non-condensing |
| Protection | Reverse polarity, surge, short circuit |
| Housing Material | Polycarbonate; POM keys |
| Weight | 210 g |
Information About FD-XA1
The FD-XA1 is the main controller unit in the Keyence FD-X series, designed to receive measurement signals from compatible sensor heads and convert them into usable monitoring and control data. Its display system combines a four-digit seven-segment display, an OLED display, output indicators, and stability-level information for operational monitoring. The controller supports selectable NPN or PNP outputs, analog current signals, and IO-Link communication for integration with industrial automation equipment. Its configurable detection modes, stored measurement data, and support for up to seven expansion units allow it to accommodate different flow monitoring and dispensing applications.
Key Features:
- DIN Rail Mounting: Main controller unit designed for installation on a standard DIN rail.
- Multi-Format Display: Combines a four-digit display, OLED screen, output indicators, and stability-level indication.
- Configurable Detection Modes: Supports instantaneous flow, area, pulse, accumulated flow, and shot measurement modes.
- Flexible Outputs: Selectable NPN/PNP open-collector outputs and configurable analog current output.
- IO-Link Communication: Supports IO-Link v1.1, COM2 at 38.4 kbps.
- Adjustable Response Time: Selectable response times from 50 ms to 60 seconds.
- Data Retention: EEPROM stores accumulated measurement data, with a specified retention period exceeding 10 years.
- Expandable Configuration: Supports up to seven expansion units per main controller.
The FD-XA1 delivers the reliability and precision required for industrial flow monitoring, liquid dispensing, and automated process control.
