Kidde Edwards WG4WF-HVMHC Genesis WG4 High-Candela Outdoor Horn Strobe White FIRE
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: WG4WF-HVMHC
Description
The Kidde Edwards WG4WF-HVMHC is a Genesis WG4 Series high-output horn-strobe designed for indoor, outdoor, wet, and harsh-environment fire alarm notification applications. Kidde Edwards part number WG4WF-HVMHC combines a field-configurable piezoelectric horn with a clear-lens xenon strobe offering 102, 123, 147, and 161 candela settings in a white enclosure marked FIRE.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Kidde Edwards |
| Category | Fire Alarm & Life Safety |
| Part Number | WG4WF-HVMHC |
| Subcategory | Outdoor Horn Strobes |
| Series | Genesis WG4 Series |
| Product Type | High-Candela Horn-Strobe Notification Appliance |
| Housing Color / Marking | White / FIRE |
| Light Source | Xenon Strobe |
| Lens | Clear |
| Candela Settings | 102, 123, 147, 161 cd |
| Audible Device | Piezoelectric Horn |
| Horn Settings | Field-Selectable Pattern and Volume |
| Fire Alarm Pattern | Temporal 3 Supported |
| Operating Voltage | Nominal 24 VDC / 24 VFWR |
| Synchronization | Genesis Synchronization Compatible |
| Mounting Orientation | Wall or Ceiling |
| Environment | Indoor / Outdoor / Wet / Harsh Locations |
| Operating Temperature | -40°F to 151°F (-40°C to 66°C) |
| Field Wiring | 12–18 AWG |
| Installation Wiring | Room-Side Connection |
| Primary Application | Audible/Visual Fire Alarm Notification |
| Weight | Approx. 1.5 lb (0.68 kg) |
Information About WG4WF-HVMHC
The WG4WF-HVMHC is a Genesis WG4 Series weather-resistant audible/visual notification appliance designed for commercial and industrial fire alarm systems. Its construction combines a high-output xenon strobe, efficient piezoelectric sounder, sealed field-adjustment features, and a durable white enclosure suitable for wall or ceiling installation. The appliance operates from a nominal 24 VDC or 24 VFWR notification appliance circuit and provides selectable horn volume, audible signaling patterns, and high-candela visual output to accommodate different notification requirements. Genesis synchronization capability, room-side wiring, an externally viewable candela setting, and optional weather-sealing accessories simplify integration into applications such as parking structures, warehouses, process areas, and exposed commercial facilities.
Key Features:
- High-Candela Strobe: Provides selectable 102, 123, 147, or 161 cd visual output for demanding notification applications.
- Xenon Light Source: Uses a high-intensity xenon flash tube with a clear lens for highly visible alarm signaling.
- Piezoelectric Horn: Integrated high-efficiency sounder provides audible fire alarm notification with selectable operating characteristics.
- Field-Selectable Output: Candela, horn volume, and supported audible pattern settings can be configured during installation.
- Temporal 3 Signaling: Supports the standardized Temporal 3 fire evacuation horn pattern.
- Genesis Synchronization: Supports synchronized visual signaling when connected to compatible Genesis synchronization equipment.
- Indoor/Outdoor Construction: Designed for indoor, outdoor, wet, and harsh-environment installations when properly mounted.
- Wide Temperature Range: Rated for operation from -40°F to 151°F (-40°C to 66°C).
- Wall or Ceiling Mounting: Flexible construction permits installation in either wall-mounted or ceiling-mounted orientations.
- Visible Candela Setting: Sealed viewport allows the selected candela rating to be checked after the appliance is installed.
- Room-Side Wiring: Electrical connections are completed from the room side to simplify installation and service.
- FIRE Identification: White housing carries FIRE marking for clear identification as a fire alarm notification appliance.
The WG4WF-HVMHC delivers the reliability and precision required for high-output audible and visual fire alarm notification in indoor, outdoor, wet, and harsh-environment applications.
