Kidde-Fenwal 06-220113-001 AEGIS Fire Alarm Control Panel Main PCB Board
- Regular price
- $1,905.00
- Sale price
- $1,905.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 06-220113-001
Description
The Kidde-Fenwal 06-220113-001 is a main printed circuit board designed for the Kidde AEGIS conventional fire alarm and suppression control unit. It provides the core processing and control interface required for detection, notification, supervisory, and suppression functions within the AEGIS system. Kidde documentation identifies 06-220113-001 specifically as the PCB supplied in the AEGIS control unit.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Kidde-Fenwal |
| Category | Fire Alarm & Suppression Systems |
| Part Number | 06-220113-001 |
| Subcategory | Fire Alarm Control Panel Boards |
| Product Type | Main Control Printed Circuit Board |
| Compatible Platform | Kidde AEGIS |
| Associated Part Number | 06-129923-005 |
| Assembly Level | Level 3 |
| Input Voltage | 115 VAC / 230 VAC |
| Input Current | 3.2 A at 115 VAC / 1.6 A at 230 VAC |
| Input Frequency | 50/60 Hz |
| Associated DC Output | +27 VDC, 5.6 A |
| Power Section Reference | EM-150-27V |
| Power Resistor | 5.1 kΩ, 0.5 W |
| PCB Classification | 94V-0 |
| Application | Fire Alarm and Suppression Control |
| Weight | 3.7 kg (8.16 lb) |
Information About 06-220113-001
The 06-220113-001 is a Kidde-Fenwal main control PCB associated with the AEGIS fire alarm and suppression control platform. The AEGIS architecture is a microprocessor-based conventional control system designed for fire alarm monitoring and suppression-discharge applications. The supplied assembly information references 06-129923-005, Level 3 construction, 50/60 Hz operation, and an EM-150-27V power section. Available exact-part documentation specifies 115 VAC at 3.2 A or 230 VAC at 1.6 A input and +27 VDC at 5.6 A output for the associated assembly.
Key Features:
- AEGIS System Integration: Designed as the main PCB for the Kidde AEGIS conventional fire alarm and suppression control unit.
- Main Control Function: Provides central electronic processing and system-control functions within the compatible panel.
- Fire and Suppression Application: Supports an architecture intended for both fire alarm monitoring and suppression discharge control.
- Dual AC Input Support: Associated assembly specifications identify 115 VAC at 3.2 A and 230 VAC at 1.6 A input capability.
- 50/60 Hz Operation: Designed for operation with either 50 Hz or 60 Hz AC power configurations.
- 27 VDC Power Section: Associated assembly information specifies a +27 VDC, 5.6 A output.
- Level 3 Assembly: Exact-part listings identify the board/assembly as a Level 3 configuration.
- 5.1 kΩ Component Specification: Product identification information specifies a 5.1 kΩ, 0.5 W resistor value.
The 06-220113-001 delivers the reliability and precision required for centralized fire alarm monitoring and suppression-system control.
