Kidde-Fenwal 70-200200-003 SmartOne Addressable Signal Module ASM
- Regular price
- $489.00
- Sale price
- $489.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 70-200200-003
Description
The Kidde-Fenwal 70-200200-003 is a SmartOne Addressable Signal Module (ASM) designed to provide a supervised notification appliance circuit for compatible intelligent fire alarm and suppression systems. It can supply either 24 VDC for conventional notification appliances such as horns and strobes or 25 Vrms for compatible speakers, allowing additional signaling devices to be controlled from the system.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Kidde-Fenwal |
| Category | Fire Alarm Systems |
| Part Number | 70-200200-003 |
| Subcategory | Addressable Signal Modules |
| Product Series | SmartOne |
| Model | ASM |
| Product Type | Addressable Signal Module |
| Primary Function | Notification Appliance Circuit Control |
| Operating Voltage Range | 18.5–27.5 VDC |
| Current Draw | 500 µA, Standby or Alarm |
| Notification Output | 24 VDC Regulated |
| Maximum NAC Output | 2 A at 24 VDC |
| Speaker Output | 20 W Maximum at 25 Vrms |
| NAC Wiring | Class A or Class B |
| Compatible Appliances | Horns, Strobes and Speakers |
| Mounting | Standard Square Electrical Box |
| Weight | 10.5 oz (298 g) |
Information About 70-200200-003
The 70-200200-003 is a Kidde-Fenwal SmartOne Series addressable signal module featuring enhanced firmware while retaining the functionality of the earlier 70-200200-001 ASM. Its intelligent architecture incorporates a microprocessor, memory, and onboard electronics for communication through the SmartOne signaling line circuit of a compatible control unit. The module can be field-configured for either a 24 VDC notification appliance circuit or a 25 Vrms speaker circuit and supports Class A or Class B NAC wiring. It installs in a standard square electrical box and is compatible with Kidde intelligent control units operating with the SmartOne communication protocol.
Key Features:
- Addressable Signal Control: Provides an intelligent addressable output circuit for fire alarm notification equipment.
- 24 VDC NAC Output: Supports conventional notification appliances including additional horns and strobes.
- Speaker Circuit Capability: Can be configured to provide a 25 Vrms output for compatible fire alarm speakers.
- Class A or Class B Wiring: Supports either Class A or Class B notification appliance circuit configurations.
- 2 A Output Rating: Provides a maximum regulated notification output of 2 A at 24 VDC.
- SmartOne Communication: Connects to compatible Kidde intelligent control units through the SmartOne signaling line circuit.
- Enhanced Firmware: Provides the functionality of the 70-200200-001 with updated firmware.
- Low SLC Current: Draws approximately 500 µA from the signaling line circuit during standby or alarm conditions.
The 70-200200-003 delivers the reliability and precision required for addressable control of horns, strobes, speakers, and other compatible fire alarm notification appliances.
