KMC Controls BAC-5901ACE BACnet Advanced Application Controller
- Regular price
- $835.00
- Sale price
- $835.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BAC-5901ACE
Description
The KMC Controls BAC-5901ACE is a BACnet Advanced Application Controller (B-AAC) designed for precise control of HVAC and building automation systems. Featuring an integrated actuator, built-in Ethernet, and flexible I/O, it provides a scalable solution for Variable Air Volume (VAV), air handling, boiler, and chiller applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | KMC Controls |
| Part Number | BAC-5901ACE |
| Alternate Part Number | KMCBAC-5901CE |
| Category | HVAC |
| Subcategory | HVAC Control System Board |
| Product Type | BACnet Advanced Application Controller (B-AAC) |
| Series | BAC-5900 |
| Communication Protocols | BACnet/IP, BACnet MS/TP |
| Network Interface | Built-In Ethernet |
| Universal Inputs | 8 |
| Outputs | 8 |
| Expandable I/O Capacity | Up to 74 Inputs and 40 Outputs (with CAN-5900 Modules) |
| Integrated Actuator | Yes |
| Configuration | HTML5 Web Server, NFC Mobile Configuration |
| Applications | VAV Systems, Air Handling Units, Boilers, Chillers, Building Automation |
| Weight | 0.5 kg |
Information About BAC-5901ACE
The BAC-5901ACE is part of the KMC Controls BAC-5900 Series of programmable BACnet controllers developed for commercial building automation systems. It combines an advanced application controller with an integrated actuator, reducing installation time while providing reliable control for VAV boxes and other HVAC equipment. Supporting both BACnet/IP and BACnet MS/TP communication, the controller integrates easily into modern building management systems while offering browser-based configuration and NFC setup capabilities. Its expandable architecture allows additional I/O modules to be connected, making it suitable for projects ranging from individual zones to large commercial facilities.
Key Features:
- Integrated Actuator: Combines controller and actuator in a single compact device.
- BACnet/IP and BACnet MS/TP: Supports multiple BACnet communication protocols for seamless system integration.
- 8 Universal Inputs and 8 Outputs: Provides flexible I/O for a wide range of HVAC control applications.
- Expandable I/O Capacity: Supports CAN-5900 Series expansion modules for up to 74 inputs and 40 outputs.
- Built-In Ethernet: Enables fast network connectivity and browser-based configuration.
- HTML5 Web Server: Allows convenient setup and diagnostics using standard web browsers.
- NFC Configuration: Supports mobile configuration even when the controller is not powered.
- Fully Programmable: Suitable for VAV systems, air handling units, boilers, chillers, and other building automation equipment.
The BAC-5901ACE delivers the reliability, flexibility, and performance required for advanced HVAC and building automation control.
