LC36400 | Schneider Electric Circuit Breaker
- Regular price
- $4,037.00
- Sale price
- $4,037.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: LC36400
Description
The LC36400 is a circuit breaker from the LC series, specifically designed for I-Line applications, with a current rating of 400A and featuring three poles. This thermal magnetic circuit breaker provides basic protection against overloads and short circuits, ensuring the manual and automatic interruption of circuits when necessary.
Primarily utilized in industrial enclosures, panelboards, switchboards, busway plug-in units, combination starters, and motor control centers, the LC circuit breakers offer versatile applications in various electrical setups.
Technical Specifications
|
Part Number |
LC36400 |
|
Manufacturer |
Schneider Electric / Square D |
|
Family |
I-Line |
|
Pole |
3 |
|
Amp |
400 |
|
Volt |
600 |
|
Phase |
3 |
|
Category |
Molded Case / 3-Pole |
|
Connection |
I-Line Style Plug-In |
|
Type |
LC |
|
Functions |
LI - Long-Time and Instantaneous |
|
Protection |
Thermal Magnetic |
|
Frame Type |
L Frame |
|
AIC Ratings |
65kA@480V |
Information About LC36400
Square D LC molded case circuit breakers, such as the LC36400, offer fundamental thermal magnetic protection, facilitating manual and automatic circuit opening under overload or short circuit scenarios. These circuit breakers, categorized under LC and LI series, find application across industrial enclosures, panelboards, switchboards, busway plug-in units, combination starters, and motor control centers.
The LC36400, a 3-pole I-line plug-in circuit breaker, features a thermal magnetic trip unit with a rated current of 400A and a voltage of 600VAC. With an Extra High Interrupting rating of 35kA at 600VAC, it ensures robust circuit protection. Notably, all LA molded case circuit breakers are equipped with trip indication, indicated by the operating handle being in a central position upon tripping.
These circuit breakers are commonly integrated into I-line combo panels, accommodating terminal wire ranges for AL600LI35, spanning 2 wires from AWG to 350 kcmil in aluminum or copper.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
