Product Description P/N: LGA36600U31X
Description
The LGA36600U31X from the PowerPacT L series is a robust circuit breaker designed to safeguard electrical systems against overloads and short circuits. Featuring a 600A current rating across 3 poles, it operates at 600VAC and offers an interrupting capacity of 18kA, ensuring reliable performance under demanding conditions.
Equipped with MicroLogic Standard trip unit technology with a 3.3 version and LI function, this breaker provides precise protection and control. It includes I-Line terminations on the line side and mechanical lugs on the load side, facilitating secure electrical connections.
Technical Specifications
|
Part # |
LGA36600U31X |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Range |
PowerPact |
|
Product name |
PowerPact L |
|
Device short name |
L-Frame |
|
Product or Component Type |
Circuit breaker |
|
Device Application |
Distribution |
|
Line Rated Current |
600 A |
|
Number of Poles |
3P |
|
Control Type |
Toggle |
|
Breaking capacity code |
G |
|
[Ue] rated operational voltage |
600 V AC 50/60 Hz IEC 60947-3 |
|
Network Frequency |
50/60 Hz |
|
[Uimp] rated impulse withstand voltage |
8 kV IEC 60947-2 |
|
Trip unit technology |
Electronic, standard, MicroLogic 3.3, LI |
|
Continuous current rating |
80 % |
|
[Ui] rated insulation voltage |
750 V IEC 60947-2 |
|
Trip unit name |
MicroLogic 3.3 |
|
Protection technology |
Current limiter |
|
Suitability for isolation |
Yes IEC 60947-2 |
|
Utilisation category |
Category A |
|
AWG gauge |
2 x AWG 2/0...500 kcmil aluminium/copper |
|
Mounting mode |
I-Line bracket) |
|
Mounting Support |
Bracket |
|
Electrical connection |
I-Line connection, line |
|
|
Lugs, load |
|
Terminal identifier |
AL600LF52K3 |
|
Long time pick-up adjustment range |
0.25...1 x In |
Information About LGA36600U31X
The LGA36600U31X is a circuit breaker from the PowerPacT L series designed specifically for protecting electrical systems against overloads and short circuits. Featuring electronic trip units, PowerPacT L-Frame circuit breakers incorporate dual-break rotating contacts to mitigate peak current during short circuit faults. Each breaker includes an integral push-to-trip button on the cover for manual operation.
Available in configurations supporting 3 and 4 poles, unit mount, I-Line, and drawout installations, the PowerPacT L series caters to diverse application needs. This particular model, rated at 600A and 600VAC, boasts an interrupting capacity of 18kA. It utilizes a MicroLogic 3.3 trip unit, providing standard protection with an LI function. The circuit breaker is equipped with I-Line terminations on the line side and mechanical lugs on the load side, facilitating secure connections.
With a continuous current rating of 80% and designed for ABC phase connection compatibility, PowerPacT L circuit breakers adhere to rigorous safety and performance standards, including UL, CSA, NOM, and IEC certifications. Additionally, they are CE marked, ensuring compliance with European Union regulations.
