Product Description P/N: LHL36200

Description / Specifications

Description

The LHL36200 is a Square D LH molded case circuit breaker designed to provide thermal magnetic protection. These circuit breakers automatically open a circuit under overload or short circuit conditions or can be manually opened. Each pole of LH circuit breakers contains thermal (overload) and magnetic (short circuit) sensing elements.

Featuring Push-to-Trip functionality, this circuit breaker allows for manual tripping without exposure to live parts. The LHL36200 is a 3 pole unit mount breaker rated at 200A and 600VAC. It has an interrupting rating of 25kA for 600VAC and 50kA for 250VDC.



Technical Specifications

Part #

LHL36200

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Line Rated Current

200 A

Number of Poles

3P

Breaking Capacity Code

H

Mounting Mode

Unit mount

Magnetic Hold Current

1000 A

Magnetic Tripping Current

2000 A

Height

11 in (279.40 mm)

Width

6 in (152.40 mm)

Depth

5.84 in (148.34 mm)

Circuit Breaker Application

HACR rated



Information About LHL36200

The LHL36200 is a molded case circuit breaker manufactured by Square D, designed to provide thermal magnetic protection. It functions to automatically open a circuit under overload or short circuit conditions, or can be manually opened. Each pole of LH circuit breakers contains thermal (overload) and magnetic (short circuit) sensing elements. The inclusion of Push-to-Trip functionality allows for manual tripping of the circuit breaker without exposing live parts.

This particular Square D LH circuit breaker is a 3 pole unit mount breaker rated at 200A and 600VAC. It features a thermal magnetic circuit breaker with an interrupting rating of 25kA for 600VAC and 50kA for 250VDC.

LH breakers adhere to several certification standards, including UL 489, CSA, and IEC certifications. These certifications ensure that the circuit breaker meets the required safety and performance standards set by regulatory bodies.
