LP-RPM-2U-120 | Lutron LCP128 Remote Dimming Module, 120 V – 2-Output, 16A per Zone
- Regular price
- $1,549.00
- Sale price
- $1,549.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: LP-RPM-2U-120
Description
The Lutron LP-RPM-2U-120 is a remote dimming module engineered for LCP128 lighting control panels. This unit provides precise dimming capabilities for two independent outputs at 120 V. It is ideal for expanding panel capacity in commercial and architectural lighting systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Lighting Control Systems
|
| Part Number | LP-RPM-2U-120 |
| Subcategory | Dimming Modules |
| Series | LCP128 |
| Module Type | Remote Dimming Module (2-Output) |
| Voltage Rating | 120 V AC 50/60 Hz |
| Load Rating | 25 W min, 16 A per output, 16 A per module |
| Control Method | Dimming (Square Law) |
| Compatible Loads | Incandescent, MLV, Neon, Tu-Wire |
| Integration | LCP128 Panels via Class 2 Low-Voltage Wiring |
| Surge Protection | Up to 6000 V / 3000 A |
| Operating Temperature | 32–104 °F (0–40 °C) |
| Enclosure Rating | NEMA Type 1, IP20 |
| Certifications | UL, CSA, CEC, NOM, Seismic |
| Mounting | Surface/Recess-mount in LCP128 Panel |
| Weight | 14 kg (panel mini), 37 kg (standard – panel) |
Information About LP-RPM-2U-120
The LP-RPM-2U-120 belongs to the Lutron LCP128 Series, delivering robust dimming performance for distributed lighting control systems. Rated for 16 A per output (25 W minimum load), this module supports incandescent, magnetic low-voltage, neon, Tu-Wire, and compatible electronic load types. It integrates via low-voltage Class 2 wiring and is controlled by the LCP128 LCD processor for scheduled or manual scene selection. Designed for seamless inclusion inside pre-wired LCP128 panels, it maintains system reliability and flicker-free performance through RTISS filter technology.
Key Features:
- Dual Output Dimming: Controls two independent 16 A dimming circuits at 120 V.
- Panel Integration: Installs directly in LCP128 dimming panels for system scalability.
- Wide Load Support: Operates incandescent, magnetic low-voltage, neon, and Tu-Wire loads.
- Flicker-Free Operation: Includes RTISS filtering for line-voltage fluctuation compensation.
- Lightning Protection: Built to withstand surges up to 6000 V and 3000 A.
- Power-Failure Memory: Restores previous lighting state after outages for continuity.
- Rugged Construction: Enclosed in NEMA-1 steel housing for indoor environments.
- The LP-RPM-2U-120 delivers the reliability and precision required for architectural dimming systems.
