LSYKB1A-8C | Honeywell HDLS Limit Switch Wobble Coil Spring SPDT 1NC/1NO
- Regular price
- $383.00
- Sale price
- $383.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: LSYKB1A-8C
Description
The Honeywell LSYKB1A-8C Limit Switch is a heavy-duty, snap-action industrial switch designed for precise mechanical control and position detection. It features a wobble coil spring actuator, SPDT contact configuration, and durable die-cast zinc housing, providing reliable performance in demanding low-temperature environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Industrial Controls |
| Part Number | LSYKB1A-8C |
| Subcategory | Limit Switch |
| Series | HDLS Series |
| Family Name | LS Series Family |
| Type | Heavy-Duty Limit Switch |
| Actuator Type | Wobble Coil Spring |
| Action Type | Double Break / Snap Action |
| Contact Form | SPDT (1NO / 1NC) |
| Current Rating | 10A |
| Voltage Rating (AC Max) | 600V AC |
| Operating Force | 1.95 N (7 ozf) |
| Operation Mode | Momentary |
| Material | Die-Cast Zinc |
| Head Type | Wobble Head |
| Termination | Screw Terminals |
| Connection Type | 1/2-14 NPT Conduit Entry |
| Mounting Type | Chassis Mount |
| IP Rating | IP65 |
| NEMA Rating | 1, 3, 4, 4X, 6, 6P, 12, 13 |
| Operating Temperature Range | -29°C to +121°C |
| Standards Compliance | UL, CSA, CE |
| Illuminated | Non-Illuminated |
| Country of Origin | United States |
| Weight | 1.00 lbs |
Information About LSYKB1A-8C
The LSYKB1A-8C is part of Honeywell’s HDLS (Heavy-Duty Limit Switch) Series, built to provide precise and dependable performance in industrial automation and machine control systems. This model features a wobble coil spring actuator that delivers multidirectional operation, allowing the switch to detect mechanical movement from various angles. Its SPDT double-break contacts ensure reliable circuit interruption even under high current loads. Designed for harsh conditions, it meets IP65 and multiple NEMA enclosure standards, offering protection against dust, water, and oil ingress. Its die-cast zinc body and sealed design make it suitable for outdoor or heavy mechanical use in low-temperature industrial settings.
Key Features:
- Heavy-Duty Construction: Die-cast zinc housing and sealed design provide rugged durability for industrial use.
- Wobble Coil Spring Actuator: Flexible multidirectional actuation allows detection of movement from multiple approach angles.
- Snap-Action Contacts: Double-break mechanism ensures fast, reliable switching and longer mechanical life.
- SPDT Configuration: Provides both normally open (NO) and normally closed (NC) contacts for versatile control applications.
- High Electrical Ratings: Handles up to 10A at 600V AC, suitable for demanding industrial loads.
- Environmental Protection: Rated IP65 and NEMA 1, 3, 4, 4X, 6, 6P, 12, 13 for resistance to moisture, dust, and corrosion.
- Wide Temperature Range: Operates reliably from -29°C to +121°C, making it suitable for cold and high-temperature environments.
- Standards Certified: Complies with UL, CE, and CSA standards for safety and performance.
The LSYKB1A-8C delivers the reliability and precision required for position sensing, machine control, and industrial automation systems operating in challenging environments.
