MAC Valves 811C-PM-502JD-155 4-Way Piloted Solenoid Valve 24VDC 6W
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 811C-PM-502JD-155
Description
The MAC Valves Inc 811C-PM-502JD-155 is a heavy-duty 4-way balanced piloted spool solenoid valve designed for high-flow pneumatic control and fast cycling in automated industrial systems. Operating on a 24 VDC power supply with a 6 W power rating, it features an illuminated rectangular connector (JD) for clear visual status diagnostics and a locking manual operator for convenient setup and testing. Engineered around MAC's balanced spool technology, this valve provides dependable, pressure-independent performance across demanding production machinery.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | MAC Valves Inc |
| Category | Valves |
| Part Number | 811C-PM-502JD-155 |
| Subcategory | Solenoid Valve |
| Series | 800 Series (811C) |
| Valve Function | 4-Way Balanced Piloted Spool |
| Supply Voltage | 24 VDC |
| Power Consumption | 6 W |
| Manual Operator | Locking Style |
| Electrical Interface | Rectangular Connector with LED Light (JD) |
| Mounting Type | Sub-Base / Manifold Mount |
| Weight | 2.50 kg |
Information About 811C-PM-502JD-155
The 811C-PM-502JD-155 belongs to MAC Valves' 800 Series of high-flow piloted spool valves engineered to maximize shifting speed and airflow consistency. Its balanced spool design ensures that shifting forces remain unaffected by inlet line pressure fluctuations, preventing valve sticking and ensuring repeatable cycle times during continuous duty. Compatibility extends to standard 24 VDC control outputs, industrial PLC I/O modules, and modular sub-base or manifold piping systems. It is widely applied in heavy packaging lines, automotive stamping systems, material transfer equipment, and primary industrial pneumatic circuits.
Key Features:
- Valve Series: MAC Valves 811C Series 4-way balanced piloted spool valve
-
Supply Voltage: 24 VDC operating power rating
-
Power Consumption: 6 W energy-efficient solenoid coil
-
Manual Override: Locking manual operator for safe manual testing and setup
-
Electrical Connector: Rectangular plug connector with integrated LED status light (JD)
-
Flow Design: High-capacity balanced spool for fast, consistent pneumatic response
-
Construction Weight: Heavy-duty 2.50 kg industrial valve assembly
The 811C-PM-502JD-155 delivers the reliability and precision required for high-flow pneumatic actuation and automated system control.
