MAC Valves Inc. 36A-E00-JDNB-1BA 12V DC Solenoid Valve
- Regular price
- $127.00
- Sale price
- $127.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 36A-E00-JDNB-1BA
Description
The MAC Valves Inc. 36A-E00-JDNB-1BA is a 3-way, 2-position solenoid valve designed to control compressed-air flow in industrial pneumatic systems. It uses a 12 V DC solenoid and belongs to MAC Valves' Series 36 family, which features a balanced poppet design for consistent switching performance. This particular configuration is reported as discontinued by a supplier, which recommends part number 121324 as a replacement.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | MAC Valves Inc. |
| Category | Pneumatic Equipment |
| Part Number | 36A-E00-JDNB-1BA |
| Subcategory | Pneumatic Solenoid Valves |
| Product Series | 36 Series |
| Product Type | Direct-Acting Solenoid Valve |
| Valve Function | 3-way, 2-position |
| Operating Voltage | 12 V DC (supplier-listed) |
| Coil Power | 0.15 W (supplier-listed for this configuration) |
| Pressure Range | 30–120 psi (supplier-listed) |
| Lead Length | 24 in |
| Replacement Part | 121324 (supplier-recommended; confirm compatibility) |
| Weight | 0.25 lb |
Information About 36A-E00-JDNB-1BA
The 36A-E00-JDNB-1BA is a MAC Valves Series 36 pneumatic valve intended for electrically controlled switching in automation equipment. Supplier specifications identify a 3-way, 2-position configuration, 12 V DC operation, and 24-inch coil leads. The Series 36 platform uses direct solenoid actuation and a balanced poppet design to support fast response and reliable switching. Before ordering a replacement, verify the original valve's electrical connection, mounting arrangement, and pneumatic function because this specific part number is listed as discontinued.
Key Features:
-
3-Way Valve Design: Directs compressed air between supply, outlet, and exhaust paths.
-
2-Position Operation: Switches between two valve states for pneumatic control.
-
12 V DC Solenoid: Supplier-listed electrical operating voltage.
-
Series 36 Construction: Part of MAC Valves' compact pneumatic valve family.
-
Balanced Poppet Design: Helps maintain consistent switching forces despite pressure variations.
-
24-Inch Coil Leads: Electrical leads are listed at 24 inches for connection to the control circuit.
-
Industrial Pneumatic Control: Suitable for compatible automation and machinery applications.
-
Replacement Identification: Supplier recommends part number 121324 for replacement; verify compatibility before substitution.
The 36A-E00-JDNB-1BA provides electrically controlled pneumatic switching for compatible industrial automation systems.
