Product Description P/N: MDL3800F
Description
The Eaton MDL3800F is an 800A, 600V molded case circuit breaker frame from the Series C MDL line, engineered for high-capacity three-phase power distribution. This M-Frame device supports thermal-magnetic protection with LSI (Long-Time, Short-Time, and Instantaneous) trip functions and provides a 50 kA interrupting rating at 480V. Supplied as a frame only, it is intended for use with compatible trip units and accessories in heavy-duty industrial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | MDL3800F |
| Subcategory | Molded Case Circuit Breaker |
| Family | Series C |
| Type | MDL |
| Voltage Rating | 600 V |
| Amperage Rating | 800 A |
| Functions Supported | LSI – Long-Time, Short-Time & Instantaneous |
| Protection Type | Thermal Magnetic (with compatible trip unit) |
| Frame Type | M Frame |
| AIC Rating | 50 kA @ 480 V |
| Connection Style | Bolt-On |
| Poles | 3 |
| Phase | 3-Phase |
| Configuration | Frame Only |
Information About MDL3800F
The MDL3800F belongs to Eaton’s Series C MDL family, a range of molded case breakers designed for large-scale electrical distribution systems requiring robust construction and flexible protection capabilities. As an M-Frame assembly, this model provides the structural housing, terminals, and mechanical interface for 800A applications while accepting Series C trip units for full functionality. The frame supports LSI protection, enabling advanced coordination through Long-Time, Short-Time, and Instantaneous trip functions once equipped with the proper trip unit. With a 50 kA interrupt rating at 480V and bolt-on connection capability, the MDL3800F integrates securely into industrial power panels and switchboards where high fault-handling capacity and reliable mounting are essential.
Key Features:
- Frame-only configuration: Provides housing and terminals for 800A MDL trip units.
- M-Frame design: Heavy-duty molded case construction suited for high-power systems.
- Supports LSI trip functions: Long-Time, Short-Time, and Instantaneous protection when equipped with the appropriate trip unit.
- Thermal-magnetic protection capability: Designed to operate with Series C thermal-magnetic trip units.
- 50 kA interrupting rating @ 480V: Handles high fault currents in industrial environments.
- 3-pole configuration: Suitable for three-phase distribution networks.
- Bolt-on connection: Ensures secure installation in panelboards and switchboards.
- 600V maximum rating: Supports a broad range of heavy-duty electrical applications.
The MDL3800F delivers the reliability and precision required for integrating high-capacity protection components into industrial electrical distribution systems.
