Metasys AS-UNT141-1 UNT111 Unitary Controller with Screw Terminals
- Regular price
- $1,367.00
- Sale price
- $1,367.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: AS-UNT141-1
Description
The Metasys AS-UNT141-1 is a Johnson Controls UNT111 unitary controller designed for HVAC and building automation applications. It provides six binary outputs, two analog outputs, isolated N2 communication, and selectable high- or low-side triac operation for controlling compatible HVAC equipment. The controller can operate as part of a Metasys network or as a standalone unit.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Johnson Controls / Metasys |
| Category | HVAC & Building Automation |
| Part Number | AS-UNT141-1 |
| Subcategory | Unitary Controllers |
| Series | Metasys UNT |
| Device Type | Unitary Controller |
| Controller Type | UNT111 |
| Binary Outputs | 6 |
| Analog Outputs | 2 |
| Analog Output Signal | 0–10 VDC |
| Analog Output Rating | 10 mA |
| N2 Communication | Yes |
| N2 Bus | Isolated |
| Zone Bus | 6-pin phone jack |
| I/O Terminations | Fixed screw terminal block |
| Triac Outputs | 24 VAC |
| Triac Rating | 0.5 A, up to 0.8 A with total power limitation |
| Power Supply | 24 VAC, 50/60 Hz |
| Typical System Power | 40 VA |
| Processor | 80C652 |
| RAM | 32K |
| ROM | 64K |
| EEPROM | 8K |
| Operating Temperature | 0–52°C / 32–125°F |
| Relative Humidity | 10–90% RH |
| Storage Temperature | -40–70°C / -40–158°F |
| Dimensions | 6.5 × 6.4 × 2.2 in. |
| Weight | 1.4 lb |
Information About AS-UNT141-1
The AS-UNT141-1 is the screw-terminal version of the UNT111 controller, providing fixed screw terminals for field wiring and a spare 6-pin Zone Bus phone jack. It operates from a 24 VAC supply and includes an 80C652 processor, 32K RAM, 64K ROM, and 8K EEPROM. The controller is intended for applications such as unit ventilators, fan coils, heat pumps, air-handling units, and other terminal HVAC equipment.
Key Features:
- Unitary Controller: Provides programmable control for compatible HVAC equipment.
- Six Binary Outputs: Provides six 24 VAC triac outputs for connected equipment.
- Two Analog Outputs: Provides 0–10 VDC analog control outputs at up to 10 mA.
- N2 Communication: Supports communication with Johnson Controls Metasys systems.
- N2 Isolation: Provides isolated N2 bus communication.
- Screw Terminals: Uses fixed screw terminals for field I/O connections.
- Zone Bus Interface: Includes a spare 6-pin Zone Bus phone jack.
- Standalone Operation: Can operate independently or as part of a Metasys network.
The AS-UNT141-1 provides configurable I/O and network communication for compatible HVAC control applications.
