Metasys DX-9100-8990 Panel Mounting Base for Digital Controller
- Regular price
- $649.00
- Sale price
- $649.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: DX-9100-8990
Description
The Metasys DX-9100-8990 is a panel-mounting base designed for Johnson Controls Metasys DX-9100 Extended Digital Controllers. It provides the physical mounting platform for compatible DX-9100 Version 2 and Version 3 controllers, including the DX-9120 TP78 Version 3 configuration. The base is installed separately from the controller and does not include terminal covers.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Johnson Controls / Metasys |
| Category | HVAC & Building Automation |
| Part Number | DX-9100-8990 |
| Subcategory | Controller Mounting Bases |
| Series | Metasys DX-9100 |
| Device Type | Panel Mounting Base |
| Application | DX-9100 Extended Digital Controllers |
| Compatible Controllers | DX-9100 Versions 2 and 3 |
| Compatible Controller | DX-9120 TP78 Version 3 |
| Mounting Style | Panel Mount |
| Material | Plastic |
| Terminal Covers | Not Included |
| Mounting Screws | 4 |
| Screw Diameter | 4.2 mm |
| Operating Temperature | 0Β°C to 40Β°C / 32Β°F to 104Β°F |
| Operating Humidity | 10β95% RH, non-condensing |
| Storage Temperature | -20Β°C to 70Β°C |
| Storage Humidity | 5β95% RH |
| Relative Humidity | 10β90%, non-condensing |
| Storage Temperature | -20β70Β°C / 0β160Β°F |
| Weight | 1.50 lb |
Information About DX-9100-8990
The DX-9100-8990 is a mounting base rather than the complete DX-9100 controller. Johnson Controls documentation specifies that the base is reused when installing compatible adapter assemblies and confirms the DX-9100-8990 designation for the controller base. It is designed for panel mounting and provides open access for field wiring. The base is compatible with DX-9100 Extended Digital Controller Versions 2 and 3 and is identified as a discontinued product by current distributors.
Key Features:
- Panel Mounting Base: Provides a secure mounting platform for compatible DX-9100 controllers.
- DX-9100 Compatibility: Designed for Extended Digital Controller Versions 2 and 3.
- TP78 Support: Compatible with the DX-9120 TP78 Version 3 controller configuration.
- Open Wiring Access: Provides access to controller terminals for field wiring.
- Plastic Construction: Uses a durable plastic housing for the mounting assembly.
- Four Mounting Screws: Secures the base to a panel using four surface mounting screws.
- Replacement Component: Can be used as a replacement base for compatible DX-9100 installations.
- Adapter Compatibility: The base can be reused with specified Johnson Controls adapter assemblies.
The DX-9100-8990 provides the mounting foundation required for compatible Metasys DX-9100 controller installations.
