MGL36800 | Square D PowerPacT M-Frame 800A 3-Pole 600V Electronic LI Feed-Thru Molded Case Circuit Breaker
- Regular price
- $3,745.00
- Sale price
- $3,745.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: MGL36800
Description
The Square D MGL36800 is an 800-amp, 3-pole molded case circuit breaker designed for high-capacity 600-volt electrical distribution systems. Equipped with an electronic 1.0 LI trip unit, it provides Long-Time and Instantaneous protection for heavy-duty installations. With a 35 kA interrupting rating at 480V and feed-thru construction, the MGL36800 offers reliable performance in commercial and industrial power systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | MGL36800 |
| Subcategory | Molded Case Circuit Breaker |
| Manufacturer | Schneider Electric |
| Type | MGL |
| Frame Type | M Frame |
| Amperage Rating | 800 A |
| Poles | 3 |
| Phase | 3-Phase |
| Voltage Rating | 600 VAC |
| AIC Rating | 35 kA @ 480V |
| Max AIR Rating | 18 kA (600V) |
| Trip Type | Electronic (ET 1.0) |
| Functions | LI – Long-Time, Instantaneous |
| Protection | Solid-State Electronic |
| Connection | Feed-Thru (Lug-In / Lug-Out) |
| Terminal Connection | Box Lug |
| Phase Connection | ABC |
| Min. Wire Size | 3/0 AWG |
| Max. Wire Size | 500 kcmil |
| Mounting Type | Lug-In / Lug-Out Panel Mount |
| Continuous Current Rating | 80% |
| Compliance | UL, CSA, NOM, IEC, CE Marked |
| Application | High-capacity commercial and industrial distribution systems |
Information About MGL36800
The MGL36800 belongs to the Square D PowerPacT M-Frame family, a series engineered for robust overload and short-circuit protection in large-scale electrical distribution applications. It features a solid-state electronic trip unit (ET 1.0) with fixed Long-Time and Instantaneous functionality, delivering accurate protection without the need for interchangeable plugs. The breaker includes lugs on both the line and load sides, supporting simple feed-thru installation in panelboards and switchgear. With an 800-amp rating, 600-volt capability, and compliance with UL, CSA, NOM, and IEC standards, the MGL36800 is well suited for demanding industrial environments requiring reliable high-capacity protection.
Key Features
- 800A molded case breaker: Supports heavy-duty electrical distribution loads.
- 3-pole PowerPacT M-Frame construction: Suitable for three-phase systems.
- Electronic 1.0 trip unit: Provides Long-Time and Instantaneous (LI) protection.
- 35 kA interrupting rating at 480V: Delivers strong short-circuit clearing capability.
- Feed-thru configuration: Includes lugs on both line and load sides for flexible installation.
- Solid-state protection: Ensures accurate fault sensing and improved system coordination.
- Box-lug terminals: Accept a wide conductor range for installation flexibility.
- Certified to UL, CSA, NOM, and IEC standards: Ensures compliance in global applications.
The MGL36800 delivers the reliability and precision required for high-capacity PowerPacT M-Frame electrical distribution systems.
