Product Description P/N: MJA36800E10

Description / Specifications

Description

The MJA36800E10 is a Circuit Breaker belonging to the PowerPacT M series, designed to protect electrical systems from damage caused by overloads and short circuits. Specifically, this circuit breaker offers a current rating range of 300A to 800A, configured with 3 poles and a voltage rating of 600VAC. It features an adjustable trip mechanism, enabling trip setting adjustments between 300A to 800A via a selector switch.

Equipped with I-Line terminations on the line side and mechanical lugs on the load side, this circuit breaker provides versatile installation options. It boasts an interrupting rating of 25kA at 600VAC and operates at a continuous current rating of 80% with an ABC phase connection. The circuit breaker is outfitted with an integral push-to-trip button in the cover, facilitating manual tripping.



Technical Specifications

Part #

MJA36800E10

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Line Rated Current

300…800 A

Number of Poles

3P

Control Type

Operating handle

Breaking capacity code

J

[Ue] rated operational voltage

600 V AC 50/60 Hz UL 489

Network Frequency

50/60 Hz

[Ics] rated service breaking capacity

35 kA 240 V AC 50/60 Hz IEC 60947-2



25 kA 380/415 V AC 50/60 Hz IEC 60947-2

[Uimp] rated impulse withstand voltage

8 kV IEC 60947-2

Trip unit technology

Electronic, basic, ET 1.0

Magnetic tripping current

1600…8000 A

Continuous current rating

80 %

[Ui] rated insulation voltage

750 V IEC 60947-2

Trip unit name

ET 1.0

Accessory / separate part type

Communication module

Suitability for isolation

Yes IEC 60947-2

Utilisation category

Category A

AWG gauge

3 x AWG 3/0...3 x 500 kcmil aluminium/copper

Local signalling

1 trip indicator (green)

Mounting mode

I-Line bracket)

Mounting Support

Bracket

Electrical connection

I-Line connection, line



Lugs, load

Terminal identifier

AL800M23K

Long time pick-up adjustment range

300...800 A

Mounting Height

9 in (228.60 mm)

Tightening torque

442.54 lbf.in (50 N.m) 0.15…0.37 in² (95…240 mm²)



(3 x AWG 3/0...3 x 500 kcmil)

Power wire stripping length

0.98 in (25 mm)

Color

Black

Height

12.86 in (326.64 mm)

Width

8.27 in (210.06 mm)

Depth

8.05 in (204.47 mm)

Net Weight

29 lb(US) (13.15 kg)

Quantity per Set

1

Communication interface

Modbus

Circuit breaker application

HACR rated

IP degree of protection

IP40

Pollution degree

3 IEC 60947-1

Ambient air temperature for operation

-13…158 °F (-25…70 °C)

Ambient Air Temperature for Storage

-58…185 °F (-50…85 °C)



Information About MJA36800E10

The MJA36800E10 is a Circuit Breaker belonging to the PowerPacT M series, engineered to safeguard electrical systems against damage resulting from overloads and short circuits. These M-Frame circuit breakers come equipped with either a fixed long-time electronic trip unit or an adjustable amperage version, the latter of which allows for trip setting adjustments ranging from 300A to 800A via a selector switch.

Featuring an integral push-to-trip button in the cover, all PowerPacT circuit breakers enable manual tripping. Available in both 2 and 3-pole unit mount or I-Line construction, this particular unit is configured with I-Line terminations on the line side and mechanical lugs on the load side.

With an interrupting rating of 25kA at 600VAC, this circuit breaker offers robust protection capabilities. Additionally, it boasts a continuous current rating of 80% with an ABC phase connection.





Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
