MS4-TH-MSTP | Alerton Microset 4 Touchscreen Thermostat, BACnet MS/TP, Temperature/RH/CO₂ Sensing
- Regular price
- $742.00
- Sale price
- $742.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: MS4-TH-MSTP
Description
The Alerton MS4-TH-MSTP is a Microset 4 electronic thermostat and wall sensor designed for modern building automation environments. Its hardened glass touchscreen interface provides clear display of temperature, humidity, and system status while allowing intuitive occupant interaction. Fully compatible with Alerton BACtalk™ systems, it supports enhanced control capabilities and seamless integration into existing HVAC networks.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Alerton |
| Category | Controls & Indicators |
| Part Number | MS4-TH-MSTP |
| Subcategory | Electronic Thermostat / Wall Sensor |
| Operating Temperature | 50–113 °F (10–45 °C) |
| Humidity Sensor Accuracy | ±3% RH (10–90% RH), ±5% RH (0–10% & 90–100% RH) |
| Humidity Repeatability | ±0.5% RH Minimum |
| CO₂ Sensor Operating Temp. | -32–122 °F (0–50 °C) |
| CO₂ Measurement Range | 0–5000 ppm |
| CO₂ Accuracy | ±30 ppm, ±3% of reading |
| Communication Protocol | BACnet MS/TP |
| Certifications | EMC Directive 89/336/EEC, FCC Part 15 Class B, UL 916 |
| Display | Capacitive Touch Backlit Glass |
| Functions | Temperature, RH, Fan Status, Optional CO₂, LED Status Indicator |
| Application | Building Automation, Zone HVAC Control |
Information About MS4-TH-MSTP
The MS4-TH-MSTP is part of Alerton’s Microset 4 sensor lineup, engineered to deliver touchscreen-based environmental control with BACnet MS/TP communication. It presents setpoint information, room and outdoor temperatures, relative humidity, and fan operation, all through a high-durability glass capacitive display. A configurable LED status indicator provides quick feedback on heating and cooling modes. The device is backward compatible with Alerton BACtalk™ controllers, enabling use as a zone control interface, service tool, or commissioning aid. Optional CO₂ sensing expands its capability for indoor air-quality monitoring, while its intuitive 30-minute occupancy control features support energy-efficient operation in intermittently used spaces. With a contemporary aesthetic and robust sensing performance, the MS4-TH-MSTP is suited for commercial, institutional, and high-performance building environments.
Key Features
- Touchscreen glass interface: Displays temperature, setpoints, RH, CO₂ (if equipped), and fan status.
- BACnet MS/TP communication: Ensures seamless integration with Alerton BACtalk™ systems.
- Configurable LED status light: Provides quick visual indication of heating or cooling modes.
- Multiple sensing capabilities: Supports temperature, humidity, and optional CO₂ measurement.
- ±3% RH accuracy: High-precision humidity sensing for reliable environmental monitoring.
- Backward compatibility: Functions as a tenant interface, test-and-balance tool, and field service tool.
- Energy-management features: Supports occupant control, scheduling increments, and optional lighting/fan control.
- Durable construction: Hardened edge-to-edge glass with a capacitive backlit display for long-term use.
The MS4-TH-MSTP delivers the precision sensing, intuitive control, and integration flexibility required for advanced building automation systems.
Description
The Alerton MS4-TH-MSTP is a Microset 4 electronic thermostat and wall sensor designed for modern building automation environments. Its hardened glass touchscreen interface provides clear display of temperature, humidity, and system status while allowing intuitive occupant interaction. Fully compatible with Alerton BACtalk™ systems, it supports enhanced control capabilities and seamless integration into existing HVAC networks.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Alerton |
| Category | Controls & Indicators |
| Part Number | MS4-TH-MSTP |
| Subcategory | Electronic Thermostat / Wall Sensor |
| Operating Temperature | 50–113 °F (10–45 °C) |
| Humidity Sensor Accuracy | ±3% RH (10–90% RH), ±5% RH (0–10% & 90–100% RH) |
| Humidity Repeatability | ±0.5% RH Minimum |
| CO₂ Sensor Operating Temp. | -32–122 °F (0–50 °C) |
| CO₂ Measurement Range | 0–5000 ppm |
| CO₂ Accuracy | ±30 ppm, ±3% of reading |
| Communication Protocol | BACnet MS/TP |
| Certifications | EMC Directive 89/336/EEC, FCC Part 15 Class B, UL 916 |
| Display | Capacitive Touch Backlit Glass |
| Functions | Temperature, RH, Fan Status, Optional CO₂, LED Status Indicator |
| Application | Building Automation, Zone HVAC Control |
Information About MS4-TH-MSTP
The MS4-TH-MSTP is part of Alerton’s Microset 4 sensor lineup, engineered to deliver touchscreen-based environmental control with BACnet MS/TP communication. It presents setpoint information, room and outdoor temperatures, relative humidity, and fan operation, all through a high-durability glass capacitive display. A configurable LED status indicator provides quick feedback on heating and cooling modes. The device is backward compatible with Alerton BACtalk™ controllers, enabling use as a zone control interface, service tool, or commissioning aid. Optional CO₂ sensing expands its capability for indoor air-quality monitoring, while its intuitive 30-minute occupancy control features support energy-efficient operation in intermittently used spaces. With a contemporary aesthetic and robust sensing performance, the MS4-TH-MSTP is suited for commercial, institutional, and high-performance building environments.
Key Features
- Touchscreen glass interface: Displays temperature, setpoints, RH, CO₂ (if equipped), and fan status.
- BACnet MS/TP communication: Ensures seamless integration with Alerton BACtalk™ systems.
- Configurable LED status light: Provides quick visual indication of heating or cooling modes.
- Multiple sensing capabilities: Supports temperature, humidity, and optional CO₂ measurement.
- ±3% RH accuracy: High-precision humidity sensing for reliable environmental monitoring.
- Backward compatibility: Functions as a tenant interface, test-and-balance tool, and field service tool.
- Energy-management features: Supports occupant control, scheduling increments, and optional lighting/fan control.
- Durable construction: Hardened edge-to-edge glass with a capacitive backlit display for long-term use.
The MS4-TH-MSTP delivers the precision sensing, intuitive control, and integration flexibility required for advanced building automation systems.
