MVI56E-GSC | ProSoft Generic ASCII Serial Enhanced Interface
- Regular price
- $3,152.00
- Sale price
- $3,152.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: MVI56E-GSC
Description
The ProSoft MVI56E-GSC is an enhanced generic ASCII serial communication module specifically designed for integration with the Allen-Bradley ControlLogix platform. This versatile module provides reliable and powerful ASCII communication capabilities, enabling seamless integration of serial devices into ControlLogix-based automation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | ProSoft |
| Category |
PLCs/Machine Control
|
| Part Number | MVI56E-GSC |
| Subcategory | PLC Module/Rack |
| Series | MVI56E |
| Protocol | Generic ASCII Serial |
| Communication Ports | 1 x RS-232 Configuration Port (RJ45), 2 x RS-232/422/485 Communication Ports (RJ45) |
| Backplane Current Load | 800 mA at 5 VDC, 3 mA at 24 VDC |
| Voltage Rating | 5/24 VDC |
| Temperature Rating | Operating: 32°F to 140°F (0°C to 60°C); Storage: -13°F to 158°F (-25°C to 70°C) |
| Connectivity | CIPconnect for ControlNet and EtherNet/IP |
| Weight | 0.22 lbs |
Information About MVI56E-GSC
The MVI56E-GSC module is part of the ProSoft MVI56E series, known for enhanced functionality and robust communication support. It features a dedicated RS-232 serial configuration port (CFG, RJ45) and two powerful, fully configurable RS-232/422/485 serial communication ports (P1/P2, RJ45). This allows it to connect a wide range of serial devices, such as barcode scanners, weigh scales, printers, and legacy systems, to ControlLogix controllers.
Key Features:
- Fully Configurable ASCII Communication Ports: Provides two RS-232/422/485 ports that can be independently configured for various baud rates, parity settings, and communication requirements.
- Dedicated Configuration Port: Includes a separate RS-232 configuration port for simplified module setup and management.
- CIPconnect Technology: Supports bridging over Rockwell Automation ControlNet and EtherNet/IP networks, enhancing connectivity and system integration.
- Onboard Web Server: Facilitates local and remote diagnostics, module monitoring, and easy access to documentation and sample programs.
- Robust Operating Temperature Range: Functions reliably in temperatures from 32°F to 140°F (0°C to 60°C), and stores safely in temperatures down to -13°F (-25°C), making it suitable for a variety of industrial installations.
- ControlLogix Integration: Designed for seamless integration with Allen-Bradley ControlLogix PLCs, ensuring easy deployment in existing systems.
- Low Power Consumption: Requires only 800 mA at 5 VDC and 3 mA at 24 VDC from the backplane, minimizing its impact on system power resources.
- Protocol Support: Facilitates generic ASCII serial communication, allowing integration with a wide range of third-party devices and legacy equipment.
The MVI56E-GSC module is an essential solution for connecting legacy and modern serial devices to ControlLogix controllers, offering enhanced diagnostics, reliable performance, and easy configuration.
