MVI69-MCM | Allen-Bradley Modbus Master/Slave Network Interface Module
- Regular price
- $2,679.00
- Sale price
- $2,679.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: MVI69-MCM
Description
The MVI69-MCM is a Modbus Master/Slave communication module from Allen-Bradley, designed for use with CompactLogix controllers. It enables seamless integration of Modbus RTU devices into Rockwell Automation systems by supporting both Modbus master and slave configurations.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
PLCs and Accessories
|
| Part Number | MVI69-MCM |
| Subcategory |
PLC Expansion Modules
|
| Rockwell Compatible Series | CompactLogix |
| Slot | 1 |
| Data Transfer | Ladder Logic |
| Baud Rate | 110-115K baud |
| Current Load | 800 mA max. @ 5 VDC |
| Weight | 0.07 kgs |
Information About MVI69-MCM
The MVI69-MCM is a versatile Modbus Master/Slave communication module designed by ProSoft Technology for seamless integration with Allen-Bradley CompactLogix™ and MicroLogix™ 1500 controllers. It enables Rockwell PLCs to communicate with Modbus-compatible devices using Modbus RTU/ASCII protocols over serial connections. With dual configurable ports, broad protocol support, and robust diagnostics, the MVI69-MCM is ideal for connecting PLCs with third-party Modbus sensors, drives, meters, and remote systems in industrial automation networks.
Key Features:
-
Compatibility: Allen-Bradley CompactLogix and MicroLogix 1500 platforms
-
Protocol Support: Modbus RTU and ASCII (Master and Slave modes)
-
Communication Ports: 2 x isolated serial ports (RS-232, RS-485, RS-422)
-
Baud Rate Range: 110 to 115,200 bps
-
Supported Devices: Up to 100 Modbus slaves (master mode), 30 Modbus masters (slave mode)
-
Configuration Interface: Ladder logic-based with user-defined function blocks
-
Diagnostics: LED indicators and onboard diagnostics for real-time monitoring
-
Power Source: Backplane-powered via CompactLogix rack
-
Form Factor: Compact 1769-style slot module for easy integration
-
Application Scope: Industrial automation, legacy device integration, SCADA systems
This communication module is ideal for control engineers and system integrators who need a reliable, high-performance solution for bridging CompactLogix controllers with Modbus networks, especially in complex industrial environments such as oil & gas, water treatment, and manufacturing.
