N7K-M148GS-11L | Cisco Nexus 7000 48 Port GE Module
- Regular price
- $339.00
- Sale price
- $339.00
- Regular price
-
Couldn't load pickup availability
Do you need help?

Product Description P/N: N7K-M148GS-11L
Description
The Cisco N7K-M148GS-11L is a high-density 48-port Gigabit Ethernet module designed for the Cisco Nexus 7000 Series switches. With full-duplex operation, advanced security, and SFP-based fiber connectivity, it enables scalable and secure aggregation in data center core and distribution layers.
Technical Specifications
Condition | New/Never Used Surplus |
---|---|
Brand | Cisco |
Category |
Networking
|
Part Number | N7K-M148GS-11L |
Subcatecory |
Network Modules
|
Interface Type
|
Gigabit Ethernet |
Data Rate
|
1 Gbps |
Duplex Mode
|
Full duplex |
Jumbo Frame Support
|
Yes |
Fiber Ports Quantity
|
48 |
Fiber Optic Connector
|
SFP |
Switching Capacity
|
92 Gbps |
Forwarding Rate
|
60 Mpps |
MAC Address Table
|
128,000 entries |
Number of VLANs
|
16,384 |
Power Consumption
|
358 W (typical) |
Dimensions (W x D x H)
|
389 x 556 x 44 mm |
Weight
|
7 kg |
Information About N7K-M148GS-11L
The N7K-M148GS-11L provides 48 SFP-based Gigabit Ethernet ports with full duplex capability and jumbo frame support, allowing for efficient handling of high-throughput applications. It offers a switching capacity of 92 Gbps and a forwarding rate of 60 Mpps, making it ideal for environments requiring both speed and scalability.
Key Features:
- Type: 48-port Gigabit Ethernet line card for Cisco Nexus 7000 Series
- Port Type: SFP-based fiber optic ports for high-density fiber connectivity
- Data Rate: Supports 1 Gbps Ethernet LAN data rates on all ports
- Switching Capacity: Offers 92 Gbps total switching capacity for non-blocking throughput
- Forwarding Rate: Delivers a forwarding rate of up to 60 million packets per second (Mpps)
- Full Duplex: All ports support full duplex for maximum transmission efficiency
- Jumbo Frame Support: Enables handling of large frame sizes for optimized traffic processing
- MAC Address Table: Supports up to 128,000 MAC entries for broad network scalability
- VLAN Support: Handles up to 16,384 VLANs for extensive segmentation and isolation
- Security: Includes support for 128-bit AES hardware encryption
- Power Consumption: Operates at a typical power draw of 358 watts
- Environmental Tolerance: Operates within 5–90% relative humidity (non-condensing)
The N7K-M148GS-11L delivers high-performance, secure, and scalable fiber-based connectivity for Cisco Nexus 7000 Series, enabling reliable aggregation in large-scale data center networks.
Description
The Cisco N7K-M148GS-11L is a high-density 48-port Gigabit Ethernet module designed for the Cisco Nexus 7000 Series switches. With full-duplex operation, advanced security, and SFP-based fiber connectivity, it enables scalable and secure aggregation in data center core and distribution layers.
Technical Specifications
Condition | New/Never Used Surplus |
---|---|
Brand | Cisco |
Category |
Networking
|
Part Number | N7K-M148GS-11L |
Subcatecory |
Network Modules
|
Interface Type
|
Gigabit Ethernet |
Data Rate
|
1 Gbps |
Duplex Mode
|
Full duplex |
Jumbo Frame Support
|
Yes |
Fiber Ports Quantity
|
48 |
Fiber Optic Connector
|
SFP |
Switching Capacity
|
92 Gbps |
Forwarding Rate
|
60 Mpps |
MAC Address Table
|
128,000 entries |
Number of VLANs
|
16,384 |
Power Consumption
|
358 W (typical) |
Dimensions (W x D x H)
|
389 x 556 x 44 mm |
Weight
|
7 kg |
Information About N7K-M148GS-11L
The N7K-M148GS-11L provides 48 SFP-based Gigabit Ethernet ports with full duplex capability and jumbo frame support, allowing for efficient handling of high-throughput applications. It offers a switching capacity of 92 Gbps and a forwarding rate of 60 Mpps, making it ideal for environments requiring both speed and scalability.
Key Features:
- Type: 48-port Gigabit Ethernet line card for Cisco Nexus 7000 Series
- Port Type: SFP-based fiber optic ports for high-density fiber connectivity
- Data Rate: Supports 1 Gbps Ethernet LAN data rates on all ports
- Switching Capacity: Offers 92 Gbps total switching capacity for non-blocking throughput
- Forwarding Rate: Delivers a forwarding rate of up to 60 million packets per second (Mpps)
- Full Duplex: All ports support full duplex for maximum transmission efficiency
- Jumbo Frame Support: Enables handling of large frame sizes for optimized traffic processing
- MAC Address Table: Supports up to 128,000 MAC entries for broad network scalability
- VLAN Support: Handles up to 16,384 VLANs for extensive segmentation and isolation
- Security: Includes support for 128-bit AES hardware encryption
- Power Consumption: Operates at a typical power draw of 358 watts
- Environmental Tolerance: Operates within 5–90% relative humidity (non-condensing)
The N7K-M148GS-11L delivers high-performance, secure, and scalable fiber-based connectivity for Cisco Nexus 7000 Series, enabling reliable aggregation in large-scale data center networks.
