N7K-M224XP-23L | Cisco SFP Ethernet Module
- Regular price
- $1,589.00
- Sale price
- $1,589.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: N7K-M224XP-23L
Description
The Cisco N7K-M224XP-23L is a high-performance, high-density 24-port 10 Gigabit Ethernet module from the M2-Series, designed for the Cisco Nexus 7000 Series switches.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Network Equipment
|
| Part Number | N7K-M224XP-23L |
| Subcategory |
Ethernet Line Cards / SFP+ Modules
|
| Device Type | Switch - 24 ports - L3 |
| Enclosure Type | Plug-in module |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24 x 10 Gigabit SFP+ |
| Switching Fabric Bandwidth | 550 Gbps |
| MAC Address Table Size | 128K entries |
| Jumbo Frame Support | 9216 bytes |
| RAM | 2 GB |
| Status Indicators | Status, link/activity |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Humidity Range Storage | 5 - 95% (non-condensing) |
| Operating Temperature Range | 32-104°C |
| Storage Temperature Range | -40-150°C |
| Dimensions (WxDxH) | 15.3 in x 21.9 in x 1.7 in |
| Weight | 16.53 lbs |
Information About N7K-M224XP-23L
The Cisco N7K-M224XP-23L is a high-density 24-port 10 Gigabit Ethernet module from the M2-Series, designed for the Cisco Nexus 7000 Series switches. It offers non-blocking, line-rate 10GbE connectivity via SFP+ interfaces and includes the XL Option, enabling enhanced scalability for large-scale deployments such as data centers and service provider networks.
Key Features:
-
Port Density: 24 x 10 Gigabit Ethernet SFP+ ports
-
Performance: Non-blocking line-rate throughput on all ports
-
XL Option: Supports up to 1 million IPv4 routes and 350,000 IPv6 routes, ideal for large-scale routing tables
-
Layer Support: Comprehensive Layer 2 and Layer 3 capabilities, including MPLS and IEEE 1588 Precision Time Protocol (PTP)
-
Architecture: Distributed forwarding with two integrated forwarding engines delivering up to 120 million packets per second (Mpps) for IPv4 and 60 Mpps for IPv6
-
Compatibility: Compatible with Cisco Nexus 7000 Series chassis, including 4-, 9-, 10-, and 18-slot models
-
Hot-Swappable: Supports hot-swapping for minimal downtime during maintenance
