Product Description P/N: NBG-12WL
Description
The NBG‑12WL is a dual-action, wireless addressable manual fire alarm pull station in Notifier's SWIFT series, designed for seamless integration with wireless fire alarm control systems via a reliable bi-directional mesh network.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Notifier |
| Category | Safety Systems |
| Part Number | NBG-12WL |
| Subcategory | Safety Pull Switch |
| Maximum Operating Voltage | 3.3 VDC |
| Maximum Current Draw | 5.0 mA (LED on) |
| Average Operating Current | 210 µA |
| Maximum Transmit RF Power | 17 dBm |
| Radio Frequency Range | 902–928 MHz |
| Operating Temperature Range | 32°F to 120°F (0°C to 49°C) |
| Humidity Range | 10% to 93% non-condensing |
| Battery Type | 4 × Panasonic CR123A or 4 × Duracell DL123A |
| Battery Replacement | On “TROUBLE BATTERY LOW” signal and/or during annual maintenance |
| Dimensions (H × W × D) | 5.6" × 4.2" × 2.1" (142 mm × 107 mm × 53 mm) |
| Weight | 0.4 lbs |
Information About NBG-12WL
The NBG‑12WL is part of Notifier’s SWIFT® series of wireless addressable fire alarm pull stations, engineered to deliver dependable manual alarm activation in modern wireless fire protection systems. This dual-action model, requiring both a push-in and pull-down motion, provides secure and deliberate alarm initiation while integrating into a Class A mesh network via a SWIFT wireless gateway. The unit is powered by long-life lithium batteries and includes clear visual indicators for activation and status. Designed for ease of installation and compliance with ADA standards, the NBG‑12WL brings modern wireless flexibility to critical safety applications.
Key Features:
- Dual-Action Activation: Requires a push-in followed by a pull-down motion, minimizing false alarms and ensuring intentional activation.
- Wireless Addressable Operation: Communicates with Notifier fire alarm control panels through the SWIFT mesh wireless gateway, supporting full addressability.
- Battery-Powered: Operates using four CR123A lithium batteries with a UL-listed minimum life of two years; includes low-battery status notification.
- Visual Status Feedback: Features an LED indicator and a latching handle with bold yellow “ACTIVATED” marking upon alarm initiation.
- Key-Lock Reset: Provides secure reset using a Notifier key, ideal for controlled post-alarm handling.
- Surface Mount Design: Simple wall-mounted installation via a mounting plate with no need for conduit pull-through.
- ADA Compliant: Meets Americans with Disabilities Act pull-force requirements (≤ 5 lb) and includes Braille instructions.
- Durable Construction: Built for reliability in commercial environments with temperature tolerance from 32°F to 120°F (0°C to 49°C).
- Compact Dimensions: Measures 5.6" x 4.2" x 2.1" and weighs between 0.4 and 1.1 lbs depending on packaging.
The Notifier NBG‑12WL combines advanced wireless technology with proven manual activation reliability, making it an ideal choice for facilities where wiring constraints or building design favor wireless solutions. As part of the evolving Notifier NBG‑12 platform, it brings smart detection, easy installation, and compliance-driven design into a single, dependable device.
