NOTIFIER CPU-300 AFP-300 Intelligent Fire Alarm Control Panel Board
- Regular price
- $2,989.00
- Sale price
- $2,989.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CPU-300
Description
The NOTIFIER CPU-300 is the central processing and control board for the AFP-300 intelligent addressable fire alarm control panel. It provides one signaling line circuit for up to 198 intelligent addressable devices while managing system programming, annunciation, communication, and fire alarm control functions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | NOTIFIER |
| Category | Fire Alarm Systems |
| Part Number | CPU-300 |
| Subcategory | Fire Alarm Control Panel Boards |
| Product Type | Central Processing Unit / Control Board |
| Compatible Panel | AFP-300 |
| System Type | Intelligent Addressable Fire Alarm Control |
| Signaling Line Circuits | 1 SLC |
| Maximum Intelligent Devices | 198 |
| Maximum Intelligent Detectors | 99 |
| Maximum Monitor / Control Modules | 99 |
| Supported SLC Styles | NFPA Style 4, Style 6, Style 7 |
| Serial Communication | EIA-232 |
| Peripheral Communication | EIA-485 |
| Primary Function | Fire Alarm System Processing and Control |
| Application | Addressable Fire Detection and Alarm Control |
| Weight | Approx. 2.0 lb (0.91 kg) |
Information About CPU-300
The CPU-300 is a NOTIFIER processor board developed specifically for the AFP-300 intelligent fire alarm control system. Its integrated signaling line circuit supports up to 99 intelligent detectors and 99 addressable monitor or control modules, providing a total capacity of 198 intelligent devices. The board architecture includes EIA-232 and EIA-485 communication interfaces for connection to compatible printers, terminals, annunciators, and other peripheral equipment. It supports NFPA Style 4, Style 6, and Style 7 SLC configurations and interfaces with the associated AFP-300 system power supply and expansion hardware.
Key Features:
- AFP-300 Compatibility: Designed as the central processor board for the NOTIFIER AFP-300 intelligent fire alarm control panel.
- Single SLC Architecture: Provides one intelligent signaling line circuit for connected addressable field devices.
- 198-Device Capacity: Supports up to 99 intelligent detectors and 99 addressable monitor or control modules per SLC.
- Multiple SLC Styles: Supports NFPA Style 4, Style 6, and Style 7 signaling line circuit configurations.
- EIA-232 Communication: Provides serial interfaces for compatible printer and terminal connections.
- EIA-485 Interface: Supports communication with compatible remote annunciators and system peripherals.
- Intelligent System Processing: Provides centralized processing for alarm, supervisory, trouble, security, and control functions.
- Modular System Integration: Interfaces with compatible NOTIFIER power supplies, annunciators, communication equipment, and addressable devices.
The CPU-300 delivers the reliability and precision required for centralized processing and addressable device management in intelligent fire alarm systems.
Description
The NOTIFIER CPU-300 is the central processing and control board for the AFP-300 intelligent addressable fire alarm control panel. It provides one signaling line circuit for up to 198 intelligent addressable devices while managing system programming, annunciation, communication, and fire alarm control functions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | NOTIFIER |
| Category | Fire Alarm Systems |
| Part Number | CPU-300 |
| Subcategory | Fire Alarm Control Panel Boards |
| Product Type | Central Processing Unit / Control Board |
| Compatible Panel | AFP-300 |
| System Type | Intelligent Addressable Fire Alarm Control |
| Signaling Line Circuits | 1 SLC |
| Maximum Intelligent Devices | 198 |
| Maximum Intelligent Detectors | 99 |
| Maximum Monitor / Control Modules | 99 |
| Supported SLC Styles | NFPA Style 4, Style 6, Style 7 |
| Serial Communication | EIA-232 |
| Peripheral Communication | EIA-485 |
| Primary Function | Fire Alarm System Processing and Control |
| Application | Addressable Fire Detection and Alarm Control |
| Weight | Approx. 2.0 lb (0.91 kg) |
Information About CPU-300
The CPU-300 is a NOTIFIER processor board developed specifically for the AFP-300 intelligent fire alarm control system. Its integrated signaling line circuit supports up to 99 intelligent detectors and 99 addressable monitor or control modules, providing a total capacity of 198 intelligent devices. The board architecture includes EIA-232 and EIA-485 communication interfaces for connection to compatible printers, terminals, annunciators, and other peripheral equipment. It supports NFPA Style 4, Style 6, and Style 7 SLC configurations and interfaces with the associated AFP-300 system power supply and expansion hardware.
Key Features:
- AFP-300 Compatibility: Designed as the central processor board for the NOTIFIER AFP-300 intelligent fire alarm control panel.
- Single SLC Architecture: Provides one intelligent signaling line circuit for connected addressable field devices.
- 198-Device Capacity: Supports up to 99 intelligent detectors and 99 addressable monitor or control modules per SLC.
- Multiple SLC Styles: Supports NFPA Style 4, Style 6, and Style 7 signaling line circuit configurations.
- EIA-232 Communication: Provides serial interfaces for compatible printer and terminal connections.
- EIA-485 Interface: Supports communication with compatible remote annunciators and system peripherals.
- Intelligent System Processing: Provides centralized processing for alarm, supervisory, trouble, security, and control functions.
- Modular System Integration: Interfaces with compatible NOTIFIER power supplies, annunciators, communication equipment, and addressable devices.
The CPU-300 delivers the reliability and precision required for centralized processing and addressable device management in intelligent fire alarm systems.
