Notifier PSE-6 6A Remote Fire Alarm Power Supply with Battery Charger
- Regular price
- $555.00
- Sale price
- $555.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: PSE-6
Description
The Notifier PSE-6 is a 6-amp remote power supply with an integrated battery charger designed to provide regulated 24 VDC power for fire alarm notification appliance circuits and auxiliary devices. Compatible with virtually any 12V or 24V fire alarm control panel, the Notifier PSE-6 supports flexible NAC expansion, synchronized notification, and reliable backup power for commercial life safety systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Notifier |
| Category | Fire Alarm Systems |
| Part Number | PSE-6 |
| Subcategory | Remote Power Supply |
| Series | PS Series |
| Product Type | Remote Power Supply with Battery Charger |
| Output Voltage | 24 VDC regulated |
| Maximum Output Current | 6 A |
| Maximum Output per Circuit | 3 A |
| Output Circuits | Up to 5 independently configurable circuits |
| Wiring Configuration | Class B standard, Class A with optional ZNAC-PS module |
| Auxiliary Power | Resettable or non-resettable 24 VDC |
| Battery Charger | Integral charger for up to 33 Ah batteries |
| Internal Battery Capacity | Two 7 Ah or two 18 Ah batteries |
| Synchronization Protocols | System Sensor, Wheelock, Gentex, AMSECO |
| Input Control Circuits | 2 fully isolated programmable inputs |
| Trouble Relays | Two Form C normally closed trouble relays |
| Configuration | Onboard DIP switches |
| Wire Size | Up to 12 AWG (3.1 mm²) |
| Enclosure | Locking heavy-gauge steel cabinet with powder-coated finish |
| Compatible Panels | Any UL 864 FACP using reverse-polarity NAC circuits |
| Standards | UL 864, UL 1481, NFPA 72 |
| Approvals | UL, ULC, FM, CSFM, FDNY |
| Weight | Approximately 12.0 lb (5.4 kg) |
Information About PSE-6
The PSE-6 is part of the NOTIFIER PS Series remote power supply family, developed to expand notification appliance circuits and auxiliary power capacity in fire alarm installations. It delivers up to 6 amps of regulated 24 VDC output and supports both Class A and Class B wiring configurations when used with the optional ZNAC-PS converter module. The unit includes an integrated battery charger capable of charging batteries up to 33 Ah and provides programmable outputs for notification appliances, smoke detectors, annunciators, door holders, and other system peripherals. Designed for dependable life safety applications, it offers configurable synchronization protocols, multiple diagnostic features, and compatibility with industry-standard reverse-polarity fire alarm control panels.
Key Features:
- 6 Amp Power Output: Supplies up to 6 amps of regulated 24 VDC power for fire alarm devices.
- Multiple Configurable Outputs: Supports up to five independently programmable output circuits.
- Class A or Class B Operation: Compatible with both wiring styles using the optional ZNAC-PS converter.
- Integrated Battery Charger: Charges batteries up to 33 Ah with built-in charging circuitry.
- Flexible Auxiliary Power: Provides resettable or non-resettable 24 VDC power for peripheral devices.
- NAC Synchronization: Supports System Sensor, Wheelock, Gentex, and AMSECO synchronization protocols.
- Cascading Capability: Allows connection of up to four power supplies within a single system.
- Programmable Input Circuits: Includes two fully isolated input/control circuits assignable to any output.
- Advanced Diagnostics: Features individual NAC status LEDs, trouble history, and AC trouble delay timer.
- DIP Switch Configuration: Complete setup without requiring software programming.
- Heavy-Duty Steel Enclosure: Locking corrosion-resistant cabinet with removable terminal blocks for simplified installation.
- Wide FACP Compatibility: Operates with UL 864 listed fire alarm control panels using reverse-polarity NAC circuits.
The PSE-6 delivers the reliability and precision required for expanding notification appliance circuits and auxiliary power in commercial fire alarm systems.
